Fujitsu Through Hole Signal Relay, 24V dc Coil, 1A Switching Current, DPDT
- RS Stock No.:
- 195-8111
- Mfr. Part No.:
- RY-24W-K
- Brand:
- Fujitsu
Bulk discount available
Subtotal (1 unit)**
£2.32
(exc. VAT)
£2.78
(inc. VAT)
29 In stock - FREE next working day delivery available*
61 In stock - FREE next working day delivery available
61 In stock - FREE next working day delivery available
10 available from Europe for delivery within 2 working day(s).
* Delivery dates may change based on your chosen quantity and delivery address.
FREE delivery for orders over £50.00
Check stock levels
Units | Per unit |
|---|---|
| 1 - 4 | £2.32 |
| 5 - 9 | £2.21 |
| 10 - 19 | £2.09 |
| 20 - 29 | £1.99 |
| 30 + | £1.89 |
**price indicative
- RS Stock No.:
- 195-8111
- Mfr. Part No.:
- RY-24W-K
- Brand:
- Fujitsu
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fujitsu | |
| Coil Voltage | 24V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | Through Hole | |
| Maximum Switching Current AC | 1 A | |
| Maximum Switching Current DC | 1 A | |
| Maximum Switching Voltage AC | 120V ac | |
| Maximum Switching Voltage DC | 60V dc | |
| Maximum Switching Power DC | 24 W | |
| Series | RY | |
| Length | 20.2mm | |
| Latching | No | |
| Depth | 9.8mm | |
| Height | 12.5mm | |
| Terminal Type | Through Hole | |
| Number of Poles | 2 | |
| Switching Current | 1A | |
| Application | Signal | |
| Minimum Operating Temperature | -30°C | |
| Contact Material | Gold Plated | |
| Isolation Coil To Contact | 1kV ac | |
| Maximum Operating Temperature | +90°C | |
| Coil Power | 200mW | |
| Coil Resistance | 2880Ω | |
| Maximum Switching Power AC | 60VA | |
Select all | ||
|---|---|---|
Brand Fujitsu | ||
Coil Voltage 24V dc | ||
Contact Configuration DPDT | ||
Mounting Type Through Hole | ||
Maximum Switching Current AC 1 A | ||
Maximum Switching Current DC 1 A | ||
Maximum Switching Voltage AC 120V ac | ||
Maximum Switching Voltage DC 60V dc | ||
Maximum Switching Power DC 24 W | ||
Series RY | ||
Length 20.2mm | ||
Latching No | ||
Depth 9.8mm | ||
Height 12.5mm | ||
Terminal Type Through Hole | ||
Number of Poles 2 | ||
Switching Current 1A | ||
Application Signal | ||
Minimum Operating Temperature -30°C | ||
Contact Material Gold Plated | ||
Isolation Coil To Contact 1kV ac | ||
Maximum Operating Temperature +90°C | ||
Coil Power 200mW | ||
Coil Resistance 2880Ω | ||
Maximum Switching Power AC 60VA | ||
