Hongfa Europe GMBH PCB Mount Signal Relay, 5V dc Coil, 2A Switching Current, DPDT
- RS Stock No.:
- 176-2891
- Mfr. Part No.:
- HFD2/005-S-D
- Brand:
- Hongfa Europe GMBH
Subtotal (1 pack of 5 units)*
£6.13
(exc. VAT)
£7.355
(inc. VAT)
FREE delivery for orders over £50.00
- 745 unit(s) ready to ship
- Plus 155 unit(s) ready to ship from another location
- Plus 4,000 unit(s) shipping from 13 November 2025
Units | Per unit | Per Pack* |
---|---|---|
5 + | £1.226 | £6.13 |
*price indicative
- RS Stock No.:
- 176-2891
- Mfr. Part No.:
- HFD2/005-S-D
- Brand:
- Hongfa Europe GMBH
Select all | Attribute | Value |
---|---|---|
Brand | Hongfa Europe GMBH | |
Coil Voltage | 5V dc | |
Contact Configuration | DPDT | |
Mounting Type | PCB Mount | |
Maximum Switching Current AC | 2 A | |
Maximum Switching Current DC | 2 A | |
Maximum Switching Voltage AC | 250V | |
Maximum Switching Voltage DC | 220V | |
Series | HFD2 | |
Maximum Switching Power DC | 90 W | |
Latching | No | |
Length | 20.2mm | |
Depth | 10.1mm | |
Height | 10.6mm | |
Dimensions | 20.2 x 10.2 x 10.6mm | |
Terminal Type | PCB Pin | |
Number of Poles | 2 | |
Switching Current | 2A | |
Minimum Operating Temperature | -40°C | |
Coil Resistance | 167Ω | |
Operating Temperature Range | -40 → +85°C | |
Maximum Switching Power AC | 125VA | |
Coil Power | 150mW | |
Contact Material | Gold Plated | |
Maximum Operating Temperature | +85°C | |
Life | 1 x 10^8 cycles | |
Features | Bifurcated Contacts, High Sensitive, High Switching Capacity | |
Relay Switching Classification | Subminiature DIP Relay | |
