Lumberg Automation Straight Female 4 way M12 to Unterminated Sensor Actuator Cable, 10m

RS Stock No.:: 197-2821
Mfr. Part No.:: 49202 RKTS 4-288/10 M
Brand:: Lumberg Automation

Lumberg Automation Straight Female 4 way M12 to Unterminated Sensor Actuator Cable, 10m

Subtotal (1 unit)*

£34.10

(exc. VAT)

£40.92

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

Plus 26 unit(s) shipping from 01 December 2025
Plus 30 unit(s) shipping from 09 January 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£34.10

*price indicative

Sensor & Actuator cables to Sensor Accessories

Complete Your Connection with the Right Accessories

Sensor & actuator cables are essential for reliable connectivity—but to get the most out of your setup, don’t overlook the accessories. From mounting hardware to protective covers and connectors, our sensor accessories help you install, secure, and optimise your system. If you're browsing cables, explore our accessories range to ensure a clean, efficient, and long-lasting installation.

Shop Now

RS Stock No.:: 197-2821
Mfr. Part No.:: 49202 RKTS 4-288/10 M
Brand:: Lumberg Automation

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lumberg Automation
	Series	RKT
	Cross Sectional Area	0.34 mm²
	Number of Cores	4
	Sheath Material	Polyurethane PUR
	Length	10m
	Sheath Colour	Black
	Connector 1 Number of Contacts	4
	Connector 1 Orientation	Straight
	Connector 1	M12
	Connector 1 Gender	Female
	Connector 2	Unterminated
	Coding	A
	Shielded/Unshielded	Shielded
	Shielding	Shielded
	Voltage Rating	60 V
	Current Rating	4 A
	IP Rating	IP65, IP67, IP69K
	Conductor Resistance	10 mΩ
	Conductor Material	Copper
	Standards Met	IEC 60754-1
	Number of Strands	4
	Operating Temperature Range	-40 → +90 °C
	Cable Shape	Round
	Outer Diameter	5.5mm
	Minimum Operating Temperature	-40°C
	Minimum Bend Radius	5 x D (Fixed Inst), 10 x D (Flexible Inst)
	Fire Behaviour	Halogen Free
	Maximum Operating Temperature	+90°C
	Insulation Material	PP
	Oil Resistant	Yes

	Select all
	Brand Lumberg Automation
	Series RKT
	Cross Sectional Area 0.34 mm²
	Number of Cores 4
	Sheath Material Polyurethane PUR
	Length 10m
	Sheath Colour Black
	Connector 1 Number of Contacts 4
	Connector 1 Orientation Straight
	Connector 1 M12
	Connector 1 Gender Female
	Connector 2 Unterminated
	Coding A
	Shielded/Unshielded Shielded
	Shielding Shielded
	Voltage Rating 60 V
	Current Rating 4 A
	IP Rating IP65, IP67, IP69K
	Conductor Resistance 10 mΩ
	Conductor Material Copper
	Standards Met IEC 60754-1
	Number of Strands 4
	Operating Temperature Range -40 → +90 °C
	Cable Shape Round
	Outer Diameter 5.5mm
	Minimum Operating Temperature -40°C
	Minimum Bend Radius 5 x D (Fixed Inst), 10 x D (Flexible Inst)
	Fire Behaviour Halogen Free
	Maximum Operating Temperature +90°C
	Insulation Material PP
	Oil Resistant Yes

COO (Country of Origin):: CZ

Belden Lumberg Automation Sensor Actuator Cable, 5.5mm OD, IP69K Rating - RKT Series - 49202 RKTS 4-288/10 M

Need to add a sensor to your setup? Join it up with this Belden Lumberg Automation sensor actuator cable. One end has a female M12 connector and the other is unterminated, so you can customise it to your needs. Thanks to gold-plated bronze pins, signals are sent speedily to support efficient communication. Wear and tear from movement and light impact is no match for this cable, thanks to its durable PVC jacket. An IP69K rating lets you know it's shielded against dust and resists high-temperature, high-pressure water jets.

Features & Benefits

• Shielded against EMI to minimise signal loss
• Lifespan of up to 100 mating cycles for long-lasting connectivity
• Long cable length of 10m gives you easy reach in larger setups

Applications

• Warehouses
• Metalworking facilities
• Packaging industry

Can I lock this product's connector in place?

Yes, the M12 socket comes with a coupling nut to secure your connection against movement.
