Bulgin Right Angle Female 5 way M8 to Unterminated Sensor Actuator Cable, 1m
- RS Stock No.:
- 144-6730
- Distrelec Article No.:
- 300-95-441
- Mfr. Part No.:
- PXPTPU08RAF05BCL010PUR
- Brand:
- Bulgin
Subtotal (1 unit)*
£30.35
(exc. VAT)
£36.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 22 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £30.35 |
*price indicative
- RS Stock No.:
- 144-6730
- Distrelec Article No.:
- 300-95-441
- Mfr. Part No.:
- PXPTPU08RAF05BCL010PUR
- Brand:
- Bulgin
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Bulgin | |
| Series | M8 | |
| Number of Cores | 5 | |
| Sheath Material | PUR | |
| Sheath Colour | Black | |
| Length | 1m | |
| Connector 1 Gender | Female | |
| Connector 1 | M8 | |
| Connector 1 Number of Contacts | 5 | |
| Connector 1 Orientation | Right Angle | |
| Connector 2 | Unterminated | |
| Coding | B | |
| Shielded/Unshielded | Unshielded | |
| Voltage Rating | 30 V | |
| Current Rating | 1.5 A | |
| IP Rating | IP67 | |
| Cable Shape | Single Core | |
| Outer Diameter | 3 → 3.5mm | |
| Maximum Operating Temperature | +80°C | |
| Operating Temperature Range | -25 → +80 °C | |
| Connector 1 Housing Gender | Female | |
| Conductor Material | Phosphor Bronze | |
| Minimum Operating Temperature | -25°C | |
| Conductor Resistance | <10 mΩ | |
