SKF Seal, Nitrile Rubber, 63mm Outside Diameter - GH 63X52X4.2-AD1

This piston seal with PTFE slide ring and O-ring energiser manufactured by SKF is a high-performance hydraulic seal designed for light to medium duty applications. With a low friction nitrile rubber construction, it offers durability and reliability for various industrial needs.

Features & Benefits

• Low friction design for smooth operation
• Suitable for light to medium duty applications
• Available in metric and inch sizes for versatility
• Fits seal housings in accordance with ISO 7425-1
• Alternatives can be produced by SKF SEAL JET systems

Applications

• Ideal for sealing piston assemblies in hydraulic systems
• Suitable for machinery requiring a high-performance hydraulic seal

Can it be used in high-pressure applications?

This seal is suitable for pressures up to 400 bar, making it ideal for various industrial settings.

Will it fit different piston groove diameters?

Yes, it is available in metric and inch sizes to accommodate a range of applications.

Is it compatible with different operating temperatures?

The seal can withstand temperatures from -40°C to 130°C, ensuring reliability in diverse conditions.

Select all	Attribute	Value
	Brand	SKF
	Inside Diameter	52mm
	Outside Diameter	63mm
	Seal Type	Hydraulic Seal
	Thickness	4.2mm
	Seal Material	Nitrile Rubber
	Minimum Operating Temperature	-20°C
	Maximum Operating Temperature	+100°C

	Select all
	Brand SKF
	Inside Diameter 52mm
	Outside Diameter 63mm
	Seal Type Hydraulic Seal
	Thickness 4.2mm
	Seal Material Nitrile Rubber
	Minimum Operating Temperature -20°C
	Maximum Operating Temperature +100°C

SKF Nitrile Rubber Seal, 52mm ID, 63mm OD, 4.2mm
