Schneider Electric Preventa XPS XPSAR 2 Auxiliary Contacts Safety Relay 115V ac, Single/Dual-Channel 7 Safety Contacts

Unavailable
RS will no longer stock this product.

Alternative

This product is not currently available. Here is our alternative recommendation.

RS Stock No.:
447-4512
Mfr. Part No.:
XPSAR351144
Brand:
Schneider Electric
Find similar products by selecting one or more attributes.
Select all

Brand

Schneider Electric

Supply Voltage

115V ac

Number of Channels

1, 2

Safety Contacts

7

Function

Emergency Stop

Auxiliary Contacts

2

Range

Preventa XPS

Safety Category ISO 13849-1

4

PL ISO 13849-1

e

SIL IEC 61508

3

Standards Met

RoHS Compliant

Depth

114mm

Width

99mm

Series

XPSAR

Performance Level

e

Length

99mm

RoHS Status: Exempt

Schneider Electric XPS AR Preventa Safety Relay Module for Light Curtains and Emergency Stops.


Schneider Electric presents the Preventa XPAR series of safety relay modules providing the ultimate solution to monitoring safety functions including removeable terminal block versions of the relay module. The Preventa XPSAR series provide you with more protection as they include a redundancy principle micro-processor technology with advanced functions. We offer you a wide range of safety relay modules making your options to choose the right relay module for monitoring required safety functions.

XPSAR Features.


  • Provides 7 N/O safety relay outputs plus 2 N/C volt free signalling output

  • 4 solid state output signals, duplicating the signalling of the LED's mounted on the front of the module

  • Monitoring of the start button or automatic starting

  • 24Vdc option incorporated for each supply voltage version

  • Compact 90mm housing

  • Can be used to monitor type 4 safety light curtains with semi-conductor outputs according to EN61496-01

  • Where the letter 'P' appears at the end of the part number this indicates that the product has removable terminal blocks

XPSAR Relay Module Applications.


All possible dangerous machinery needing protection for the machine and the operator.

  • Emergency stop and switches

  • Coded magnetic switches

  • Enabling switch

  • Sensing mats and edges

  • Two-hand control

  • Light curtains

  • Zero speed

  • Time delay

  • Lifts

  • Other applications on hydraulic and eccentric presses.

Standards

IEC 204-1; EN 292; EN 418; EN 60204-1; EN 1088

Approvals

BG, UL, CSA

Schneider Electric Safety Relay, DIN Rail Mounting, 99 (L) x 99 (W) x 114mm (D) - Preventa XPSAR Series - XPSAR351144


Fire up protective measures in a flash with this safety relay from Schneider Electric. By monitoring limit switches, emergency stop push buttons and light curtains, it catches process issues as soon as they pop up to cut the risk of equipment damage. With its 20ms reaction time, the unit quickly kicks into gear to deliver speedy fault response. Dual-channel surveillance means it watches over two safety devices, so you're spared the fuss of wiring extra modules. Thanks to the relay's solid state outputs, it automatically keeps your controller up-to-date about your safety system's status.

• Built-in LED indicators show input and output status, letting you make quick spot checks
• Supports DIN rail mounting for wide compatibility
• Labelled front plate for simple connection identification
• Compact dimensions of 99 (L) x 99 (W) x 114mm (D) to slot into busy cabinets

Applications


• Packaging industry
• Material handling
• Warehouses

What supply voltage do I need to use this safety relay?


The unit works with input voltages rated at 115V AC and 24V DC, making it a versatile fit for standard power supplies.
