Siemens 3SE5 Series Safety Enabling Switch, 5 Position, 1 NO/2 NC, IP67, IP66
- RS Stock No.:
- 153-119
- Mfr. Part No.:
- 3SE5322-0SD21-1AJ0
- Brand:
- Siemens
Subtotal (1 unit)*
£233.21
(exc. VAT)
£279.85
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £233.21 |
*price indicative
- RS Stock No.:
- 153-119
- Mfr. Part No.:
- 3SE5322-0SD21-1AJ0
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Series | 3SE5 | |
| Product Type | Safety Enabling Switch | |
| Contact Configuration | 1 NO/2 NC | |
| Number of Positions | 5 | |
| IP Rating | IP67, IP66 | |
| Terminal Type | Screw | |
| Housing Material | Plastic | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 60°C | |
| Contact Voltage | 250V | |
| Standards/Approvals | cULus, CE, EAC, UKCA, TUV, CCC | |
| Hazardous Area Certification | NO | |
| Depth | 43.8mm | |
| Mechanical Life | 1000000Cycles | |
| Length | 185mm | |
| Width | 54mm | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Series 3SE5 | ||
Product Type Safety Enabling Switch | ||
Contact Configuration 1 NO/2 NC | ||
Number of Positions 5 | ||
IP Rating IP67, IP66 | ||
Terminal Type Screw | ||
Housing Material Plastic | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 60°C | ||
Contact Voltage 250V | ||
Standards/Approvals cULus, CE, EAC, UKCA, TUV, CCC | ||
Hazardous Area Certification NO | ||
Depth 43.8mm | ||
Mechanical Life 1000000Cycles | ||
Length 185mm | ||
Width 54mm | ||
- COO (Country of Origin):
- DE
The Siemens Safety Position Switch with tumbler is an essential component designed for robust industrial applications. Engineered to ensure both safety and reliability, it offers a locking force of up to 1300 N and supports five directions of approach, making it versatile for various configurations. This device is equipped with spring lock technology and an auxiliary release, enhancing operational efficiency and safety across different working environments. Capable of withstanding extreme temperatures, the switch meets rigorous safety standards, including EN ISO 14119. The product is supplied without an actuator, allowing you to tailor your purchase according to specific requirements, adding flexibility to your setup.
Designed for extreme temperature resilience from 40 °C to +60 °C
Offers a mechanical service life of 1,000,000 operating cycles
Meets stringent safety regulations, ensuring maximum protection in use
Constructed from high quality plastic for reliability and durability
Features screw terminals for easy and secure electrical connections
IP66/IP67 rated for protection against dust and water ingress
