SICK UE410 Series Safety Controller, 8 Safety Inputs, 8 Safety Outputs

View this category

Subtotal (1 unit)*

£248.80

(exc. VAT)

£298.56

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 2 unit(s) shipping from 16 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£248.80

*price indicative

RS Stock No.:
285-4408
Mfr. Part No.:
UE410-8DI4
Brand:
SICK
Find similar products by selecting one or more attributes.
Select all

Brand

SICK

Series

UE410

Number of I/O

Revelant

Number of Safety Inputs

8

Number of Safety Outputs

8

Display Type

LED

Safety Category

4

SIL

SIL 3

Expansion Available

Yes

Terminal Type

Plug-in Spring Terminal

IP Rating

IP20, IP40

Dimensions

22.5 x 96.5 x 120.8 mm

Length

96.5mm

Depth

120.8mm

Width

22.5mm

COO (Country of Origin):
HU

Overview


The Flexi Classic modular safety controller enables straightforward configuration without any software. This allows the user to adapt the logic evaluation settings to the requirements of the application concerned. Logic functions are configured through rotary switches. These switches are located directly on the modules, enabling quick and easy commissioning. Communication between the individual modules is achieved via an internal bus, providing users interface information about the diagnostics of the safety system.

The product portfolio includes gateways, which have no influence on the adjusted logic and are used for connection to a higher-level, non-safe control. The gateways collect and forward the information of the system, ensuring quick diagnostics. The Flexi Classic also offers the Flexi Classic configurator tool as a configuration aid to provide a wiring diagram for the created project. Special modules for muting complete this product family, which provides efficient solutions for a whole host of applications.

At a glance


Rotary switch for easy function adjustment
Modular extension possible
Direct wiring for all types of sensors
Logic functions: AND, OR, muting, bypass, reset, EDM
Integration into all common fieldbuses
Integration of the Flexi Loop safe series connection
Special muting modules are able to meet all the requirements of a demanding muting application

Your Benefit


The optimal scalability thanks to the modular construction prevents redundant inputs and outputs as well as reducing hardware
Configuration via rotary switch simplifies logic configuration
Flexi Classic configurator tool offers easy logic configuration and wiring help
Complete diagnostics for the system, preventing unplanned downtime
The compact design enables significant reduction of the control cabinet width
Significantly reduced wiring compared with conventional safety solutions. Wiring with Flexi Loop is even easier.

Applications


Fields of applications
Machines with simple to medium safety logic
Safety-relevant applications for a variety of industries, e.g. electronics, robotics, packaging, logistics and automotive
