RS PRO PT100 Temperature Sensor 6 mm Dia, 50 mm Long, 3 Wire, 400 °C Max
- RS Stock No.:
- 350-404
- Brand:
- RS PRO
Subtotal (1 unit)*
£20.05
(exc. VAT)
£24.06
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 9 unit(s) ready to ship
- Plus 20 unit(s) shipping from 11 May 2026
- Plus 20 unit(s) shipping from 03 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £20.05 |
*price indicative
- RS Stock No.:
- 350-404
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Sensor Type | PT100 | |
| Product Type | Temperature Sensor | |
| Probe Length | 50mm | |
| Probe Diameter | 6mm | |
| Minimum Temperature Sensed | -50°C | |
| Maximum Temperature Sensed | 400°C | |
| Termination Type | Probe | |
| Series | RTM06 | |
| Cable Length | 2m | |
| Probe Material | Nickel Plated Brass | |
| Hazardous Area Certification | NO | |
| Number of Wires | 3 | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Sensor Type PT100 | ||
Product Type Temperature Sensor | ||
Probe Length 50mm | ||
Probe Diameter 6mm | ||
Minimum Temperature Sensed -50°C | ||
Maximum Temperature Sensed 400°C | ||
Termination Type Probe | ||
Series RTM06 | ||
Cable Length 2m | ||
Probe Material Nickel Plated Brass | ||
Hazardous Area Certification NO | ||
Number of Wires 3 | ||
- COO (Country of Origin):
- TR
RS PRO Standard Bayonet Type PT100 Thermo Resistance Temperature Sensor, 6mm Diameter, 50mm Immersion Length
The RS PRO Standard Bayonet Type PT100 Thermo Resistance Temperature Sensor is designed for precise and reliable temperature measurement. With a 6mm diameter and 50mm immersion length, it is ideal for use in machinery and panel manufacturing, as well as production and test equipment. This sensor is particularly suitable for applications in the food, chemical, and textile sectors, offering dependable performance in industrial control environments.
Features and Benefits
Max Operating Temperature 400°C: Ensures high-temperature measurement capability for demanding applications
1/4 Inch X 19 Inch Connector: Provides secure and easy connection
Protection Tube Nickel Coated Brass: Offers durability and resistance to corrosion
Sensor Type DIN/EN 60751: Complies with international standards for accuracy and reliability
Cable Type Fiber Glass Plus Fiber Glass and Braided Wire: Enhances flexibility and thermal resistance
Applications
Machinery manufacturing
Panel manufacturing
Production and test equipment
Food industry
Chemical industry
Textile industry
Industrial control
Additional Information
Sensor Type: PT100
Number Of Wires: 3
Termination Type: Bare Wire Tail
Probe Material: Brass
Process Connection: 6 mm Tube
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
