RS PRO PT100 Temperature Sensor 8 mm Dia, 50 mm Long, 3 Wire, 400 °C Max

RS Stock No.:: 350-402
Brand:: RS PRO

RS PRO PT100 Temperature Sensor 8 mm Dia, 50 mm Long, 3 Wire, 400 °C Max

Subtotal (1 unit)*

£33.13

(exc. VAT)

£39.76

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

44 unit(s) ready to ship
Plus 20 unit(s) shipping from 12 May 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£33.13

*price indicative

RS Stock No.:: 350-402
Brand:: RS PRO

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	RS PRO
	Sensor Type	PT100
	Product Type	Temperature Sensor
	Probe Length	50mm
	Probe Diameter	8mm
	Minimum Temperature Sensed	-50°C
	Maximum Temperature Sensed	400°C
	Termination Type	Probe
	Cable Length	4.1m
	Series	RTR-M08
	Probe Material	304 Stainless Steel
	Cable Entry Size	1/2 in
	Number of Wires	3
	Hazardous Area Certification	NO

	Select all
	Brand RS PRO
	Sensor Type PT100
	Product Type Temperature Sensor
	Probe Length 50mm
	Probe Diameter 8mm
	Minimum Temperature Sensed -50°C
	Maximum Temperature Sensed 400°C
	Termination Type Probe
	Cable Length 4.1m
	Series RTR-M08
	Probe Material 304 Stainless Steel
	Cable Entry Size 1/2 in
	Number of Wires 3
	Hazardous Area Certification NO

COO (Country of Origin):: TR

RS PRO Standard Bayonet Type PT100 Thermo Resistances Temperature Sensor, 8mm Diameter, 50mm Immersion Length

The RS PRO Standard Bayonet Type PT100 Thermo Resistances Temperature Sensor is designed for precise temperature measurement across various industrial applications. With an 8mm diameter and a 50mm immersion length, this RTD sensor is ideal for environments requiring accurate and reliable temperature monitoring.

Features and Benefits

Max Operating Temperature 400°C: Ensures high-temperature applications are handled effectively

1/2 Inch Fitting Nut: Provides secure and easy installation

Protection Tube AISI304 (DIN1.4301): Offers durability and resistance to corrosion

Sensor Type DIN/EN60751: Complies with international standards for reliability

Cable Type Fiber Glass Plus Fiber Glass and Braided Wire: Enhances durability and flexibility in challenging environments

Applications

Machinery Manufacturing

Panel Manufacturing

Production and Test Equipment

Industrial Control Applications

Food Industry

Chemical Industry

Textile Sector

Additional Information

Kit Contents: Includes a 4.1m cable for extended reach

Key Standards: Meets DIN/EN60751 standards for RTD sensors

Process Connection: 8mm tube for secure integration into systems
