SKF 683/672/Q Taper Roller 95.2 mm I.D Taper Roller Bearing, 168.2 mm O.D
- RS Stock No.:
- 461-370
- Mfr. Part No.:
- 683/672/Q
- Brand:
- SKF
Subtotal (1 unit)*
£256.56
(exc. VAT)
£307.87
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £256.56 |
*price indicative
- RS Stock No.:
- 461-370
- Mfr. Part No.:
- 683/672/Q
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Taper Roller Bearing | |
| Inside Diameter | 95.2 mm | |
| Bore Type | Cylindrical | |
| Cage Material | Sheet Metal | |
| Bearing Dynamic Load Rating | 288 KN | |
| Standards/Approvals | eClass, UNSPSC, RoHS | |
| Cone Width | 41.275mm | |
| Limiting Speed | 3800rpm | |
| Number of Rows | 1 | |
| Cup Width | 30.162mm | |
| Static Load Rating | 365kN | |
| Outside Diameter | 168.2 mm | |
| Bearing Type | Taper Roller | |
| Race Type | Cylindrical | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Taper Roller Bearing | ||
Inside Diameter 95.2 mm | ||
Bore Type Cylindrical | ||
Cage Material Sheet Metal | ||
Bearing Dynamic Load Rating 288 KN | ||
Standards/Approvals eClass, UNSPSC, RoHS | ||
Cone Width 41.275mm | ||
Limiting Speed 3800rpm | ||
Number of Rows 1 | ||
Cup Width 30.162mm | ||
Static Load Rating 365kN | ||
Outside Diameter 168.2 mm | ||
Bearing Type Taper Roller | ||
Race Type Cylindrical | ||
- COO (Country of Origin):
- IN
Gavin
The SKF Single Row Tapered Roller Bearing is designed to accommodate combined radial and axial loads and provide low friction during operation. The inner ring, with rollers and cage, can be mounted separately from the outer ring. This separable and interchangeable components facilitate mounting, dismounting and maintenance. By mounting one single row tapered roller bearing against another and applying a preload, a rigid bearing application can be achieved.
High radial and axial load carrying capacity
Accommodate axial loads in one direction
Low friction and long service life
Separable and interchangeable components
