NTN BK0609T2 6 mm ID Needle Roller Bearing Needle Roller, Drawn Cup, 10 mm OD
- RS Stock No.:
- 454-473
- Mfr. Part No.:
- BK0609T2
- Brand:
- NTN
Subtotal (1 unit)*
£3.29
(exc. VAT)
£3.95
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 5 unit(s) shipping from 09 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3.29 |
*price indicative
- RS Stock No.:
- 454-473
- Mfr. Part No.:
- BK0609T2
- Brand:
- NTN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NTN | |
| Product Type | Needle Roller Bearing | |
| Inside Diameter | 6 mm | |
| Race Width | 9mm | |
| Bore Type | Round | |
| Roller Material | Steel | |
| Cage Material | Nylon | |
| Bearing Material | Steel | |
| Number of Rows | 1 | |
| Static Load Rating | 2.28kN | |
| Series | BK0609T2 | |
| Maximum Speed - Oil | 37000rpm | |
| Standards/Approvals | ISO Class 0, RoHS | |
| End Type | Closed | |
| Dynamic Load Rating | 2.66kN | |
| Outside Diameter | 10 mm | |
| Maximum Speed - Grease | 25000rpm | |
| Limiting Speed | 37000, 25000rpm | |
| Internal Clearance | CN | |
| Bearing Type | Needle Roller, Drawn Cup | |
| Select all | ||
|---|---|---|
Brand NTN | ||
Product Type Needle Roller Bearing | ||
Inside Diameter 6 mm | ||
Race Width 9mm | ||
Bore Type Round | ||
Roller Material Steel | ||
Cage Material Nylon | ||
Bearing Material Steel | ||
Number of Rows 1 | ||
Static Load Rating 2.28kN | ||
Series BK0609T2 | ||
Maximum Speed - Oil 37000rpm | ||
Standards/Approvals ISO Class 0, RoHS | ||
End Type Closed | ||
Dynamic Load Rating 2.66kN | ||
Outside Diameter 10 mm | ||
Maximum Speed - Grease 25000rpm | ||
Limiting Speed 37000, 25000rpm | ||
Internal Clearance CN | ||
Bearing Type Needle Roller, Drawn Cup | ||
- COO (Country of Origin):
- JP
The NTN Drawn cup needle roller bearing offers exceptional performance and reliability for various mechanical applications. Designed with a closed end configuration, it ensures effective load distribution while minimizing friction. The unique construction provides enhanced protection against contaminants, making it suitable for both grease and oil lubrication environments. With a mass of only 0.002 kg, this lightweight bearing is perfect for applications that require efficiency without sacrificing durability. The optimal operating temperature range ensures consistent performance under varying conditions, making it a versatile choice for engineers and designers alike.
Optimised lubrication filters maximise performance longevity
Wide operating temperature range accommodates diverse environments
Dynamic and static load ratings ensure reliable performance
Compatibility with both grease and oil lubrication enhances versatility
