FAG 22316-E1-XL-K-C3 Taper 80 mm ID Spherical Roller Bearing, 170 mm OD
- RS Stock No.:
- 313-294
- Mfr. Part No.:
- 22316-E1-XL-K-C3
- Brand:
- FAG
Subtotal (1 unit)*
£338.62
(exc. VAT)
£406.34
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 27 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £338.62 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 313-294
- Mfr. Part No.:
- 22316-E1-XL-K-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 80mm | |
| Race Width | 58mm | |
| Bore Type | Taper | |
| Cage Material | Sheet Metal | |
| Series | 223..-E1-K | |
| Bearing Material | Steel | |
| Standards/Approvals | RoHS, DIN 635-2 | |
| Number of Rows | 2 | |
| Outside Diameter | 170mm | |
| Internal Clearance | C3 | |
| Static Load Rating | 510000N | |
| Dynamic Load Rating | 495000N | |
| Limiting Speed | 4250rpm | |
| Better World Claim | Extended Product Life, Saves Energy | |
| Better World Product | Yes | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 80mm | ||
Race Width 58mm | ||
Bore Type Taper | ||
Cage Material Sheet Metal | ||
Series 223..-E1-K | ||
Bearing Material Steel | ||
Standards/Approvals RoHS, DIN 635-2 | ||
Number of Rows 2 | ||
Outside Diameter 170mm | ||
Internal Clearance C3 | ||
Static Load Rating 510000N | ||
Dynamic Load Rating 495000N | ||
Limiting Speed 4250rpm | ||
Better World Claim Extended Product Life, Saves Energy | ||
Better World Product Yes | ||
- COO (Country of Origin):
- DE
The FAG Spherical Roller Bearing with tapered bore design is expertly engineered to deliver optimum performance in demanding applications. This component is constructed according to DIN 635-2, ensuring precision in every measurement. Its robust design caters to radial loads while providing substantial axial load capabilities in one and two directions. Noteworthy for its enhanced internal clearance, the bearing features a relubrication standard to maintain long-lasting functionality.
Adapted for easy installation with predefined mounting dimensions
Utilises a durable sheet metal cage for enhanced durability
Accommodates various lubrication types including grease and oil
