Molex 98266 Series, Flat Ribbon Ribbon Cable, 102 mm Length, 6, Type A to Type A
- RS Stock No.:
- 219-3598
- Mfr. Part No.:
- 982660057
- Brand:
- Molex
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 219-3598
- Mfr. Part No.:
- 982660057
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | Ribbon Cable | |
| Cable Type | Flat Ribbon | |
| Connector Type A | Type A | |
| Connector Type B | Type A | |
| Number of Contacts A | 6 | |
| Number of Contacts B | 6 | |
| Series | 98266 | |
| Cable Length | 102mm | |
| Standards/Approvals | RoHS | |
| Jacket Colour | White | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type Ribbon Cable | ||
Cable Type Flat Ribbon | ||
Connector Type A Type A | ||
Connector Type B Type A | ||
Number of Contacts A 6 | ||
Number of Contacts B 6 | ||
Series 98266 | ||
Cable Length 102mm | ||
Standards/Approvals RoHS | ||
Jacket Colour White | ||
Non Compliant
- COO (Country of Origin):
- HU
Molex Ribbon Cable, 0.5A Maximum Current Rating Per Contact, 60V AC Maximum Current Rating - 98266 Series - 982660057
Want to hook up PCBs in a flash? Pick this ribbon cable from Molex to make fuss-free board-to-board connections. It handles up to six circuits at once, so it's a versatile option that cuts down on cable clutter. Highly conductive tin-plated contacts get signals from A to B without a glitch. Installation is a doddle – just insert the item into a compatible IDC connector and clamp it shut to secure the connection.
Features & Benefits
• Flat flexible cable for easy routing around bends or through slots
• Polyester insulation shields live wires for better electrical safety
• 0.5mm pitch takes up little space in a system
Applications
• IT installations
• Medical devices
• Aerospace systems
• Industrial control panels
• Electronic equipment
Why is it necessary to connect PCBs?
Some systems have complex circuit layouts and need more than one PCB to work. Linking the boards ensures they work together.
