Eccel Technology Ltd OEM-MICODE-RS232 (000127) RFID Reader, 5V
- RS Stock No.:
- 126-2182
- Mfr. Part No.:
- OEM-MICODE-RS232 (000127)
- Brand:
- Eccel Technology Ltd
View all RF Modules
- RS Stock No.:
- 126-2182
- Mfr. Part No.:
- OEM-MICODE-RS232 (000127)
- Brand:
- Eccel Technology Ltd
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- GB
Product Details
OEM-MICODE RFID Reader Boards
The OEM-MICODE Reader Boards are complete Read/Write system for ISO14443A Mifare 1k,
Mifare 4k, Ultralight and ICODE. The Boards have an integrated PCB track antenna, LEDs, TTL serial and I/O interface. Also included on the board is power supply filtering, antenna-trimming capacitor and LEDs for visual indication of card acceptance. The J2 connector also allows the OEMMICODE board to be reprogrammed with custom firmware.
Two versions are available:
RS232 connector requiring 5 V supply (RS 1262182)
USB using USB bus for power supply (RS 1262181)
Features:
• Complete “plug-and-go” RFID Read / Write system
• Integrated PCB antenna, LEDS, RS232 or USB interface.
• Supports Mifare 1k, 4k, Ultralight and ICODE (including contactless read/write to Mifare
ProX, SmartMX / JCOP cards)
• Average current consumption down to 100 micro Amps even when fully active
• Auxiliary output options for automatic data output as serial or Wiegand protocol
Note
DESFire and Mifare PLUS cards are supported for serial number acquisition only.
RFID - Eccel
Specifications
| Attribute | Value |
| Component Type | Reader |
| Supported Bus Interfaces | RS232 |
| Supply Voltage | 5V |
| Length | 75mm |
| Width | 50mm |
