KOA, CND 1kΩ ±5% Bussed Resistor Array, 10 Resistors, 2512 (6432M), Concave
- RS Stock No.:
- 172-9103
- Mfr. Part No.:
- CND2B10TTE102J
- Brand:
- KOA
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 172-9103
- Mfr. Part No.:
- CND2B10TTE102J
- Brand:
- KOA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | KOA | |
| Resistance | 1kΩ | |
| Number of Resistors | 10 | |
| Resistor Type | Array | |
| Package/Case | 2512 (6432M) | |
| Termination Style | Concave | |
| Tolerance | ±5% | |
| Case Style | Moulded | |
| Power Rating per Resistor | 0.063W | |
| Circuit Designator | BUS | |
| Length | 6.4mm | |
| Depth | 3.1mm | |
| Height | 0.6mm | |
| Dimensions | 6.4 x 3.1 x 0.6mm | |
| Series | CND | |
| Number of Terminals | 20 | |
| Minimum Operating Temperature | -55°C | |
| Temperature Coefficient | ±200ppm/°C | |
| Maximum Operating Temperature | +125°C | |
Select all | ||
|---|---|---|
Brand KOA | ||
Resistance 1kΩ | ||
Number of Resistors 10 | ||
Resistor Type Array | ||
Package/Case 2512 (6432M) | ||
Termination Style Concave | ||
Tolerance ±5% | ||
Case Style Moulded | ||
Power Rating per Resistor 0.063W | ||
Circuit Designator BUS | ||
Length 6.4mm | ||
Depth 3.1mm | ||
Height 0.6mm | ||
Dimensions 6.4 x 3.1 x 0.6mm | ||
Series CND | ||
Number of Terminals 20 | ||
Minimum Operating Temperature -55°C | ||
Temperature Coefficient ±200ppm/°C | ||
Maximum Operating Temperature +125°C | ||
- COO (Country of Origin):
- JP
Bussed square corner resistor array
Concave or convex terminations
Less board space than individual chips
Eight bussed resistor elements included in one array
Less board space than individual chips
Eight bussed resistor elements included in one array
