Sensata / Cynergy3 PCB Reed Relay, 5 V dc Coil, SPNC, 1000 V dc Max, 3 A Max, 38 Ω
- RS Stock No.:
- 189-2415
- Mfr. Part No.:
- DBR70505U
- Brand:
- Sensata / Cynergy3
Subtotal (1 unit)*
£34.12
(exc. VAT)
£40.94
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £34.12 |
*price indicative
- RS Stock No.:
- 189-2415
- Mfr. Part No.:
- DBR70505U
- Brand:
- Sensata / Cynergy3
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Cynergy3 | |
| Contact Configuration | SPNC | |
| Product Type | Reed Relay | |
| Coil Voltage | 5 V dc | |
| Mount Type | PCB | |
| Switching Current | 3 A | |
| Switching AC Voltage | 1000 V ac | |
| Switching DC Voltage | 1000 V dc | |
| Coil Power | 50W | |
| Coil Resistance | 38Ω | |
| Terminal Type | PCB Terminal | |
| Minimum Operating Temperature | -20°C | |
| Operating Time | 2ms | |
| Switching Power | 50W | |
| Maximum Operating Temperature | 70°C | |
| Height | 18.5mm | |
| Width | 15.8 mm | |
| Length | 60mm | |
| Series | DBR | |
| Standards/Approvals | UR | |
| Isolation Coil To Contact | 17kV | |
| Contact Resistance | 50mΩ | |
| Latching | No | |
| Select all | ||
|---|---|---|
Brand Sensata / Cynergy3 | ||
Contact Configuration SPNC | ||
Product Type Reed Relay | ||
Coil Voltage 5 V dc | ||
Mount Type PCB | ||
Switching Current 3 A | ||
Switching AC Voltage 1000 V ac | ||
Switching DC Voltage 1000 V dc | ||
Coil Power 50W | ||
Coil Resistance 38Ω | ||
Terminal Type PCB Terminal | ||
Minimum Operating Temperature -20°C | ||
Operating Time 2ms | ||
Switching Power 50W | ||
Maximum Operating Temperature 70°C | ||
Height 18.5mm | ||
Width 15.8 mm | ||
Length 60mm | ||
Series DBR | ||
Standards/Approvals UR | ||
Isolation Coil To Contact 17kV | ||
Contact Resistance 50mΩ | ||
Latching No | ||
- COO (Country of Origin):
- GB
Very high isolation voltages (up to 10kV) are achieved through the use of high vacuum reed switches with Tungsten or Rhodium contacts and make these relays suitable for high reliability applications, such as cardiac defibrillators, test equipment and high voltage power supplies. The Tungsten contact relays can switch high voltages, up to 7000Vdc/ac peak to peak PCB or Panel Mount, via Nylon studs, versions are available. Connection options, for the HV, include PCB, solder turret(wire wrap), flying lead and 0.25” spade terminals.
Choice of 10kV, 7.5kV or 5kV isolation
Low contact resistance
PCB or panel mount
HV connections via flying leads, solder turret (wire wrap), or 1/4" spade terminals
Excellent AC characteristics
