Wickmann PCB Mount Reed Relay, 12V dc Coil, SPDT, 175V Max, 250 mA Max, 500Ω
- RS Stock No.:
- 174-0473
- Mfr. Part No.:
- HE721C1200
- Brand:
- Wickmann
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 174-0473
- Mfr. Part No.:
- HE721C1200
- Brand:
- Wickmann
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wickmann | |
| Contact Configuration | SPDT | |
| Coil Voltage | 12V dc | |
| Mounting Type | PCB Mount | |
| Maximum Switching Current DC | 250 mA | |
| Maximum Switching Voltage DC | 175V | |
| Coil Resistance | 500Ω | |
| Length | 19.05mm | |
| Height | 5.5mm | |
| Depth | 7.22mm | |
| Dimensions | 19.05 x 7.22 x 5.5mm | |
| Isolation Coil To Contact | 500V ac | |
| Number of Poles | 1 | |
| Maximum Switching Power DC | 5 W | |
| Terminal Type | PCB Pin | |
| Operating Temperature Range | -40 → +85°C | |
| Contact Resistance | 200 mΩ | |
| Special Features | Diode Suppression Option, External Magnetic Shield Option, Optional Coil Suppression Diode → Protect Coil Drive Circuits | |
| Operating Time Including Bounce | 3ms | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
Select all | ||
|---|---|---|
Brand Wickmann | ||
Contact Configuration SPDT | ||
Coil Voltage 12V dc | ||
Mounting Type PCB Mount | ||
Maximum Switching Current DC 250 mA | ||
Maximum Switching Voltage DC 175V | ||
Coil Resistance 500Ω | ||
Length 19.05mm | ||
Height 5.5mm | ||
Depth 7.22mm | ||
Dimensions 19.05 x 7.22 x 5.5mm | ||
Isolation Coil To Contact 500V ac | ||
Number of Poles 1 | ||
Maximum Switching Power DC 5 W | ||
Terminal Type PCB Pin | ||
Operating Temperature Range -40 → +85°C | ||
Contact Resistance 200 mΩ | ||
Special Features Diode Suppression Option, External Magnetic Shield Option, Optional Coil Suppression Diode → Protect Coil Drive Circuits | ||
Operating Time Including Bounce 3ms | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- CN
Miniature reed relay in a dual-in-line (DIL) package with a choice of normally open, normally open high-voltage, normally closed or changeover contacts capable of switching up to 300Vdc at 10W. Available with 5V, 12V and 24V coils and diode suppression. Ideally suited for security, telecom, instrumentation, process control and industrial applications.
