Eaton Residual Current Circuit Breaker with Overload Protection, 40 A Current Rating, 1-Pole, 30 mA Trip Sensitivity,

View all RCBOs

Subtotal (1 unit)*

£226.57

(exc. VAT)

£271.88

(inc. VAT)

Add to Basket
Select or type quantity
Orders below £50.00 (exc. VAT) cost £6.95.
Temporarily out of stock
  • Shipping from 25 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£226.57

*price indicative

RS Stock No.:
251-167
Mfr. Part No.:
193538 PXK-B40/1N/003-F
Brand:
Eaton
Find similar products by selecting one or more attributes.
Select all

Brand

Eaton

Product Type

Residual Current Circuit Breaker with Overload Protection

Current Rating

40 A

Range

xPole

Number of Poles

1

Series

Eaton Moeller

Trip Sensitivity

30mA

Tripping Characteristics

Type B

Mount Type

DIN Rail

Rated AC Voltage

240 V ac

Height

75mm

Width

35 mm

Depth

80mm

Breaking Capacity

10kA

Standards/Approvals

CE RoHS CE

Application

Switch Gear

COO (Country of Origin):
RO
The Eaton RCBO is a residual current circuit breaker with overcurrent protection, designed for enhanced safety. This model features a B 40A 1+N configuration, 30mA sensitivity, and type F characteristics, ensuring reliable protection against both residual currents and overcurrent conditions.

CE Marked

RoHS conform

Surge proof and 3 kA impulse withstand current

IP20 protection rated
