WIKA A-10 Series Pressure Sensor, 0bar Min, 0.6bar Max, 4 → 20 mA Output, Gauge Reading
- RS Stock No.:
- 221-8410
- Mfr. Part No.:
- 14116790
- Brand:
- WIKA
Subtotal (1 unit)*
£227.89
(exc. VAT)
£273.47
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £227.89 |
*price indicative
- RS Stock No.:
- 221-8410
- Mfr. Part No.:
- 14116790
- Brand:
- WIKA
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WIKA | |
| Pressure Reading Type | Gauge | |
| Minimum Pressure Reading | 0bar | |
| Maximum Pressure Reading | 0.6bar | |
| Accuracy | ±1 % | |
| Output Type | 4 → 20 mA | |
| Series | A-10 | |
| Supply Voltage | 8 → 30 V | |
| Housing Material | Stainless Steel | |
| IP Rating | IP65 | |
Select all | ||
|---|---|---|
Brand WIKA | ||
Pressure Reading Type Gauge | ||
Minimum Pressure Reading 0bar | ||
Maximum Pressure Reading 0.6bar | ||
Accuracy ±1 % | ||
Output Type 4 → 20 mA | ||
Series A-10 | ||
Supply Voltage 8 → 30 V | ||
Housing Material Stainless Steel | ||
IP Rating IP65 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The Wika Instruments pressure transmitter is used for general industrial applications. It also offers excellent quality and a free test protocol provides information on the measuring points recorded during manufacture. Measuring range is 0 to 0.6 bar.
Mostly used in machine building, shipbuilding, measurement and control technology
Non-linearity 0.25 % or 0.5 %
Non-linearity 0.25 % or 0.5 %
