Gems Sensors 3200 Series Pressure Sensor, 0bar Min, 160bar Max, Analogue Output, Relative Reading

View all Pressure Sensors

Subtotal (1 unit)*

£152.00

(exc. VAT)

£182.40

(inc. VAT)

Add to Basket
Select or type quantity
Last RS stock
  • Final 1 unit(s), ready to ship from another location
Units
Per unit
1 +£152.00

*price indicative

RS Stock No.:
136-5086
Mfr. Part No.:
3200B0160S05ER00
Brand:
Gems Sensors
Find similar products by selecting one or more attributes.
Select all

Brand

Gems Sensors

Pressure Reading Type

Relative

Minimum Pressure Reading

0bar

Maximum Pressure Reading

160bar

Output Type

Analogue

Media Measured

Air Fluid, Hydraulic Fluid, Hydraulic Oil, Oil

Process Connection

G1/4

Analogue Output

4 → 20 mA

Electrical Connection

4-Pin M12 x 1 Connector

Response Time

1 ms

Maximum Current

2 (Sink & Source) mA

Series

3200

Supply Voltage

8 → 30 V dc

Housing Material

17-4 PH Stainless Steel (Wetted Part)

Maximum Operating Temperature

+125°C

Minimum Operating Temperature

-40°C

IP Rating

IP65, IP67

Mounting Type

Threaded

COO (Country of Origin):
GB

Pressure Transmitters - 3100 Series M12 Connections


Gems Sensors 3100 series pressure transmitters offer consistent high levels of performance, reliability and stability in a wide range of compact package sizes. They feature all stainless steel wetted parts and a wide choice of electrical outputs to suit most applications. At the heart of the 3100 series is a sputter element that also provides exceptional temperature specifications.

Features and Benefits


High proof pressures

Broad choice of outputs

Operating temperature: -40°C to +120°C

Ideal for installations where space is at a premium

Stainless steel wetted parts

RoHS compliant

IP67 Rated

0.25% FS accuracy

M12 connections
