Omron Plug In Power Relay, 6V dc Coil, 10A Switching Current, DPDT
- RS Stock No.:
- 828-7274
- Mfr. Part No.:
- LY2 DC6
- Brand:
- Omron
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 828-7274
- Mfr. Part No.:
- LY2 DC6
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Coil Voltage | 6V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | Plug In | |
| Switching Current | 10A | |
| Number of Poles | 2 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 125V dc | |
| Length | 21.5mm | |
| Coil Resistance | 40Ω | |
| Coil Power | 900mW | |
| Depth | 36mm | |
| Height | 28mm | |
| Life | 100000000 (Mechanical) Operations, 500000 (Electrical) Operations | |
| Contact Material | Silver Alloy | |
| Minimum Operating Temperature | -25°C | |
| Series | LY2 | |
| Maximum Operating Temperature | +55°C | |
| Isolation Coil To Contact | 2kV ac | |
| Maximum Switching Power AC | 1.1 kVA | |
| Maximum Switching Power DC | 240 W | |
| Application | General Purpose, Power | |
