RS PRO PCB Mount Non-Latching Relay, 12V dc Coil, 3A Switching Current, DPDT
- RS Stock No.:
- 800-4511
- Brand:
- RS PRO
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 800-4511
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Coil Voltage | 12V dc | |
| Contact Configuration | DPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 3A | |
| Number of Poles | 2 | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 250V ac | |
| Maximum Switching Voltage DC | 220V dc | |
| Length | 20.2mm | |
| Coil Resistance | 720 Ω | |
| Coil Power | 200mW | |
| Life | 1000000 (Mechanical) Operations, 50000 (Electrical) Operations | |
| Maximum Operating Temperature | +85°C | |
| Depth | 10.2mm | |
| Isolation Coil To Contact | 1.5kV ac | |
| Height | 10.6mm | |
| Minimum Operating Temperature | -40°C | |
| Standards Met | CQC 13002095174, cULus E133481, RoHS Compliant | |
| Contact Material | Gold Plated | |
| Maximum Switching Power DC | 90 W | |
| Maximum Switching Power AC | 125VA | |
| Application | General Purpose | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Coil Voltage 12V dc | ||
Contact Configuration DPDT | ||
Mounting Type PCB Mount | ||
Switching Current 3A | ||
Number of Poles 2 | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 250V ac | ||
Maximum Switching Voltage DC 220V dc | ||
Length 20.2mm | ||
Coil Resistance 720 Ω | ||
Coil Power 200mW | ||
Life 1000000 (Mechanical) Operations, 50000 (Electrical) Operations | ||
Maximum Operating Temperature +85°C | ||
Depth 10.2mm | ||
Isolation Coil To Contact 1.5kV ac | ||
Height 10.6mm | ||
Minimum Operating Temperature -40°C | ||
Standards Met CQC 13002095174, cULus E133481, RoHS Compliant | ||
Contact Material Gold Plated | ||
Maximum Switching Power DC 90 W | ||
Maximum Switching Power AC 125VA | ||
Application General Purpose | ||
- COO (Country of Origin):
- CN
Subminiature Dip Relay
Contact Rating 2 A @ 30 V dc
Contacts: 2 Form C, DPDT
Fits standard 16 pin IC socket
Epoxy sealed for cleaning and wave soldering
Maximum soldering temperature 270° C for 5 seconds
Contacts: 2 Form C, DPDT
Fits standard 16 pin IC socket
Epoxy sealed for cleaning and wave soldering
Maximum soldering temperature 270° C for 5 seconds
Approvals
UL (File no. E133481)
