Finder PCB Mount Power Relay, 6V dc Coil, 10A Switching Current, SPDT
- RS Stock No.:
- 708-3197P
- Mfr. Part No.:
- 43.41.7.006.2000
- Brand:
- Finder
Discontinued
- RS Stock No.:
- 708-3197P
- Mfr. Part No.:
- 43.41.7.006.2000
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 6V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 10A | |
| Number of Poles | 1 | |
| Latching | No | |
| Series | 43 Series | |
| Terminal Type | Through Hole | |
| Maximum Switching Voltage AC | 400V ac | |
| Length | 30.2mm | |
| Coil Resistance | 150Ω | |
| Coil Power | 250mW | |
| Isolation Coil To Contact | 6kV | |
| Contact Material | Silver Alloy | |
| Height | 15.4mm | |
| Depth | 10.2mm | |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Maximum Switching Power AC | 2.5 kVA | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 6V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 10A | ||
Number of Poles 1 | ||
Latching No | ||
Series 43 Series | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 400V ac | ||
Length 30.2mm | ||
Coil Resistance 150Ω | ||
Coil Power 250mW | ||
Isolation Coil To Contact 6kV | ||
Contact Material Silver Alloy | ||
Height 15.4mm | ||
Depth 10.2mm | ||
Life 100000 (Electrical) cycles, 10000000 (Mechanical) cycles | ||
Maximum Operating Temperature +85°C | ||
Minimum Operating Temperature -40°C | ||
Maximum Switching Power AC 2.5 kVA | ||
43 Series
Low profile (15.4mm height)
High Isolation coil to contact: 6000Vac
Dimensions: 15.4x10.2x30.2mm
High Isolation coil to contact: 6000Vac
Dimensions: 15.4x10.2x30.2mm
Approvals
UL recognised component for Canada and US, VDE
