Finder PCB Relay, 5V dc Coil, 16A Switching Current, SPDT

RS Stock No.:: 248-2040
Mfr. Part No.:: 416190054010
Brand:: Finder

Finder PCB Relay, 5V dc Coil, 16A Switching Current, SPDT

Subtotal (1 pack of 20 units)*

£166.74

(exc. VAT)

£200.08

(inc. VAT)

FREE delivery for orders over £60.00

Stocked by manufacturer

Ready to ship from 29 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Pack*
20 +	£8.337	£166.74

*price indicative

RS Stock No.:: 248-2040
Mfr. Part No.:: 416190054010
Brand:: Finder

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Finder
	Coil Voltage	5V dc
	Product Type	Relay
	Contact Configuration	SPDT
	Mount Type	PCB
	Series	41
	Terminal Type	PCB Pin
	Switching Current	16A
	Minimum Operating Temperature	-40°C
	Switching AC Voltage	400V ac
	Maximum Operating Temperature	85°C
	Width	12.7mm
	Standards/Approvals	EAC
	Length	29mm
	Coil Power	650mW
	Height	19.3mm
	Contact Material	Silver Alloy

	Select all
	Brand Finder
	Coil Voltage 5V dc
	Product Type Relay
	Contact Configuration SPDT
	Mount Type PCB
	Series 41
	Terminal Type PCB Pin
	Switching Current 16A
	Minimum Operating Temperature -40°C
	Switching AC Voltage 400V ac
	Maximum Operating Temperature 85°C
	Width 12.7mm
	Standards/Approvals EAC
	Length 29mm
	Coil Power 650mW
	Height 19.3mm
	Contact Material Silver Alloy

COO (Country of Origin):: ES

Finder Series 41 Relay, 250/400V Maximum Switching Voltage (AC), 650mW Coil Power - 416190054010

This relay is a low-profile PCB mount device designed for a variety of applications in industrial and automation sectors. With a compact design at a height of only 15.7mm, it operates at a coil voltage of 5V DC and features a single pole, making it suitable for control and switching functions. Its specifications conform to EAC standards for dependable performance across differing environments.

Features & Benefits

• Wide ambient temperature range from -40 to +85°C

• 50000 cycles under rated load enhance electrical life

• High-voltage capability with maximum switching voltage of 250/400V

• Utilises AgNi contact material for improved durability

• Compact 3.5mm pin pitch designed for PCB applications

• Direct or socket mounting options for installation flexibility

Applications

• Used in industrial robots for control functionality

• Implemented in building automation systems such as lighting

• Applied in door and gate openers for operational efficiency

• Utilised in medical and dentistry equipment for consistency

• Suitable for timing circuits in various electronic devices

Can it withstand extreme temperatures?

Yes, it operates effectively between -40°C and +85°C.

Will it provide dependable performance in automation systems?

Yes, it meets EAC standards for consistent operation.

Is it easy to install on a PCB?

The relay can be mounted directly or via a socket for convenience.

Can it handle high switching voltages?

Yes, it supports maximum voltages of 250/400V.
