Omron PCB Non-Latching Relay, 12V dc Coil, 25A Switching Current

RS Stock No.:: 215-7267
Mfr. Part No.:: G7J-2A2B-T 12VDC
Brand:: Omron

Omron PCB Non-Latching Relay, 12V dc Coil, 25A Switching Current

Subtotal (1 unit)*

£34.71

(exc. VAT)

£41.65

(inc. VAT)

FREE delivery for orders over £60.00

Temporarily out of stock

Shipping from 06 July 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£34.71

*price indicative

RS Stock No.:: 215-7267
Mfr. Part No.:: G7J-2A2B-T 12VDC
Brand:: Omron

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Omron
	Product Type	Non-Latching Relay
	Coil Voltage	12V dc
	Mount Type	PCB
	Series	G7J
	Switching Current	25A
	Minimum Operating Temperature	-25°C
	Switching AC Voltage	240V ac
	Switching DC Voltage	30V dc
	Maximum Operating Temperature	60°C
	Coil Resistance	72Ω
	Length	30mm
	Coil Power	2W
	Height	20mm
	Width	14mm
	Standards/Approvals	UL, CSA, VDE, KEMA
	Contact Material	Silver Alloy
	Contact Resistance	100mΩ

	Select all
	Brand Omron
	Product Type Non-Latching Relay
	Coil Voltage 12V dc
	Mount Type PCB
	Series G7J
	Switching Current 25A
	Minimum Operating Temperature -25°C
	Switching AC Voltage 240V ac
	Switching DC Voltage 30V dc
	Maximum Operating Temperature 60°C
	Coil Resistance 72Ω
	Length 30mm
	Coil Power 2W
	Height 20mm
	Width 14mm
	Standards/Approvals UL, CSA, VDE, KEMA
	Contact Material Silver Alloy
	Contact Resistance 100mΩ

Datasheet - G7J-2A2B-T 12VDC

Omron G7J Series Power Relay, 12V Coil Voltage, 25A Switching Current - G7J-2A2B-T 12VDC

This power relay is a Compact electromechanical switching device designed for control and protection tasks in automation and electrical systems. It operates from a 12V DC drive and provides dual-pole switching with both normally open and normally closed contacts to manage AC and DC loads in confined installations.

Features and Benefits:

• 2W Coil consumption for reduced drive energy requirements
• 72Ω Coil resistance enabling predictable Coil current draw
• Silver alloy contacts minimise voltage drop during conduction
• 25A switching current for handling high-current loads
• 240V AC switching capability for mains-level control
• Tab Terminal with W-bracket mount for secure panel fitting

Applications

• Suitable for controlling motors and actuators in factory automation
• Ideal for power switching in control panels and distribution units
• Used with DC circuits requiring up to 30V switching for vehicle systems
• Can be used for load isolation in industrial machinery control racks

What temperature range can it operate within?

It is rated to function between -25°C and 60°C, allowing use across typical industrial ambient conditions.

How does the contact resistance affect circuit performance?

The contact resistance of 100mΩ keeps voltage drop low across the circuit, helping maintain efficiency when switching high currents.

Which approvals support deployment in regulated environments?

It carries UL, CSA, VDE and KEMA recognitions suitable for many regulated electrical applications.

What physical footprint should be allowed for mounting?

The relay measures 20mm in height, 30mm in length and 14mm in width, so allow a Compact footprint for panel layouts.
