Omron PCB Power Relay, 5V dc Coil, 10A Switching Current, SPDT
- RS Stock No.:
- 213-2138
- Mfr. Part No.:
- G5Q-1-EU DC5 (TY)
- Brand:
- Omron
Bulk discount available
Subtotal (1 reel of 500 units)*
£960.50
(exc. VAT)
£1,152.50
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 27 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 500 - 500 | £1.921 | £960.50 |
| 1000 - 1000 | £1.746 | £873.00 |
| 1500 + | £1.60 | £800.00 |
*price indicative
- RS Stock No.:
- 213-2138
- Mfr. Part No.:
- G5Q-1-EU DC5 (TY)
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Power Relay | |
| Coil Voltage | 5V dc | |
| Contact Configuration | SPDT | |
| Mount Type | PCB | |
| Series | G5Q | |
| Terminal Type | PCB Pin | |
| Switching Current | 10A | |
| Switching DC Voltage | 30V dc | |
| Switching AC Voltage | 250V ac | |
| Minimum Operating Temperature | -40°C | |
| Coil Resistance | 63Ω | |
| Maximum Operating Temperature | 105°C | |
| Length | 20mm | |
| Width | 10mm | |
| Standards/Approvals | EN/IEC, CSA certified, VDE, UL Recognised | |
| Height | 18.9mm | |
| Coil Power | 400mW | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Power Relay | ||
Coil Voltage 5V dc | ||
Contact Configuration SPDT | ||
Mount Type PCB | ||
Series G5Q | ||
Terminal Type PCB Pin | ||
Switching Current 10A | ||
Switching DC Voltage 30V dc | ||
Switching AC Voltage 250V ac | ||
Minimum Operating Temperature -40°C | ||
Coil Resistance 63Ω | ||
Maximum Operating Temperature 105°C | ||
Length 20mm | ||
Width 10mm | ||
Standards/Approvals EN/IEC, CSA certified, VDE, UL Recognised | ||
Height 18.9mm | ||
Coil Power 400mW | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
The Omron G5Q a miniature power relay with 1-pole 10A switching capacity. The PCB power relay has 5Vdc coil voltage with PCB terminals. The G5Q PCB power relay has applications such as Ideal for output applications of control equipment.
Compact single pole relay.
Excellent switching performance for a variety of load
