Relpol PCB Mount Power Relay, 3V dc Coil, 15A Switching Current, SPDT
- RS Stock No.:
- 134-8397
- Mfr. Part No.:
- RM50-3011-85-1003
- Brand:
- Relpol
Subtotal (1 unit)*
£3.76
(exc. VAT)
£4.51
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 43 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3.76 |
*price indicative
- RS Stock No.:
- 134-8397
- Mfr. Part No.:
- RM50-3011-85-1003
- Brand:
- Relpol
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Relpol | |
| Coil Voltage | 3V dc | |
| Contact Configuration | SPDT | |
| Mounting Type | PCB Mount | |
| Switching Current | 15A | |
| Number of Poles | 1 | |
| Latching | No | |
| Terminal Type | PCB Pin | |
| Maximum Switching Voltage AC | 240/277V ac | |
| Maximum Switching Voltage DC | 48V dc | |
| Length | 19mm | |
| Coil Resistance | 25Ω | |
| Coil Power | 360mW | |
| Depth | 15.4mm | |
| Minimum Operating Temperature | -30°C | |
| Standards Met | cULus | |
| Maximum Operating Temperature | +55°C | |
| Isolation Coil To Contact | 1kV ac | |
| Height | 15.5mm | |
| Life | >10000000 (Mechanical Life) cycles, >50000 (Electrical) cycles | |
| Contact Material | Silver Alloy | |
| Maximum Switching Power DC | 0.75 W | |
| Maximum Switching Power AC | 3 kVA | |
| Application | Household Equipment, Office Machines, Control Device, Alarm System, In Industrial Control, Industrial Controllers | |
Select all | ||
|---|---|---|
Brand Relpol | ||
Coil Voltage 3V dc | ||
Contact Configuration SPDT | ||
Mounting Type PCB Mount | ||
Switching Current 15A | ||
Number of Poles 1 | ||
Latching No | ||
Terminal Type PCB Pin | ||
Maximum Switching Voltage AC 240/277V ac | ||
Maximum Switching Voltage DC 48V dc | ||
Length 19mm | ||
Coil Resistance 25Ω | ||
Coil Power 360mW | ||
Depth 15.4mm | ||
Minimum Operating Temperature -30°C | ||
Standards Met cULus | ||
Maximum Operating Temperature +55°C | ||
Isolation Coil To Contact 1kV ac | ||
Height 15.5mm | ||
Life >10000000 (Mechanical Life) cycles, >50000 (Electrical) cycles | ||
Contact Material Silver Alloy | ||
Maximum Switching Power DC 0.75 W | ||
Maximum Switching Power AC 3 kVA | ||
Application Household Equipment, Office Machines, Control Device, Alarm System, In Industrial Control, Industrial Controllers | ||
