Omron Plug In Latching Power Relay, 24V ac Coil, 10A Switching Current, DPDT

View all Power Relays
Bulk discount available

Subtotal (1 unit)*

£11.72

(exc. VAT)

£14.06

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 99 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£11.72
5 - 9£11.37
10 +£10.91

*price indicative

RS Stock No.:
536-956
Mfr. Part No.:
MKS2PIN 24VAC
Brand:
Omron
Find similar products by selecting one or more attributes.
Select all

Brand

Omron

Coil Voltage

24V ac

Contact Configuration

DPDT

Mounting Type

Plug In

Switching Current

10A

Number of Poles

2

Latching

Yes

Series

MKS

Terminal Type

Plug In

Maximum Switching Voltage AC

250V ac

Maximum Switching Voltage DC

250V dc

Length

34.5mm

Coil Resistance

48.4Ω

Minimum Operating Temperature

-25°C

Depth

34.5mm

Maximum Operating Temperature

+60°C

Standards Met

cURus

Height

53.3mm

Contact Material

Silver Alloy

Maximum Switching Power AC

2.5 kVA

Maximum Switching Power DC

300 W

Application

General Purpose

Omron Power Relay, 48.4 Ω Coil Resistance, DPDT Contact - MKS2PIN AC24


This Omron MKS power relay is designed for automation and control applications. With a 24V AC coil voltage and a temperature range from -25°C to +60°C, it is versatile for various environments. The relay features a compact 34.5x34.5x53.3mm design and supports plug-in installation. Its two-pole DPDT configuration allows for versatile switching functions.

Features & Benefits


• 24V AC operating voltage for standard applications
• 10A switching current capacity for efficient load control
• DPDT configuration for versatile circuit control
• Silver alloy contacts for durability and conductivity
• Maximum switching voltage of 250V AC suitable for various circuits

Applications


• Control panels for industrial machinery
• Automation in HVAC systems
• Lighting control in commercial buildings
• Security systems for reliable operation
• Electrical systems for safe switching

Will it maintain its state after power loss?


Yes, it features latching functionality for state retention.

Is it suitable for both AC and DC switching?


Yes, it can handle up to 250V in both AC and DC.
