Omron PCB Power Relay, 12V dc Coil, 16A Switching Current, SPDT
- RS Stock No.:
- 419-283
- Mfr. Part No.:
- G5RL-1-E-HR DC12
- Brand:
- Omron
Bulk discount available
Subtotal (1 unit)*
£3.65
(exc. VAT)
£4.38
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 24 | £3.65 |
| 25 - 99 | £3.19 |
| 100 - 249 | £2.76 |
| 250 - 499 | £2.61 |
| 500 + | £2.59 |
*price indicative
- RS Stock No.:
- 419-283
- Mfr. Part No.:
- G5RL-1-E-HR DC12
- Brand:
- Omron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Omron | |
| Product Type | Power Relay | |
| Coil Voltage | 12V dc | |
| Contact Configuration | SPDT | |
| Mount Type | PCB | |
| Series | G5RL | |
| Terminal Type | Solder | |
| Switching Current | 16A | |
| Minimum Operating Temperature | -40°C | |
| Switching AC Voltage | 24V ac | |
| Switching DC Voltage | 24V dc | |
| Switching Power | 4kVA | |
| Coil Resistance | 360Ω | |
| Maximum Operating Temperature | 85°C | |
| Coil Power | 400mW | |
| Length | 29mm | |
| Standards/Approvals | RoHS | |
| Width | 12.7mm | |
| Height | 15.7mm | |
| Contact Material | Silver Alloy | |
| Contact Resistance | 100mΩ | |
| Select all | ||
|---|---|---|
Brand Omron | ||
Product Type Power Relay | ||
Coil Voltage 12V dc | ||
Contact Configuration SPDT | ||
Mount Type PCB | ||
Series G5RL | ||
Terminal Type Solder | ||
Switching Current 16A | ||
Minimum Operating Temperature -40°C | ||
Switching AC Voltage 24V ac | ||
Switching DC Voltage 24V dc | ||
Switching Power 4kVA | ||
Coil Resistance 360Ω | ||
Maximum Operating Temperature 85°C | ||
Coil Power 400mW | ||
Length 29mm | ||
Standards/Approvals RoHS | ||
Width 12.7mm | ||
Height 15.7mm | ||
Contact Material Silver Alloy | ||
Contact Resistance 100mΩ | ||
G5RL Series
Low noise "Silent" operation versions - almost inaudible, 44dB @ 15cm
High inrush versions - inrush peak currents up to 100A
AC versions - 24, 120 & 240Vac coils
Flux proof
8mm creepage/clearance between coil and contacts
Low profile: 15.7mm max height
Note
Operating temperature range -40 to 85°C (DC coil), -40 to 70°C (AC coil)
Approvals
UL, CSA, VDE
