RS PRO 1.5 mm² 5 Core Power Cable, White Polyvinyl Chloride PVC, 100m
- RS Stock No.:
- 811-4407
- Brand:
- RS PRO
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 811-4407
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | RS PRO | |
Cross Sectional Area | 1.5 mm² | |
Number of Cores | 5 | |
Sheath Colour | White | |
Length | 100m | |
Current Rating | 15 A | |
Outer Diameter | 3mm | |
Sheath Material | Polyvinyl Chloride PVC | |
Voltage Rating | 300/500 V | |
Conductor Strand Type | Stranded | |
American Wire Gauge | 15 AWG | |
Conductor Resistance | 13.3 Ω/km | |
Minimum Operating Temperature | -15°C | |
Insulation Material | PVC Type TI1 to BS7655 | |
Standards Met | BS EN 50525 | |
Number of Strands | 30 | |
Conductor Material | Copper | |
Core Strands | 30/0.25 mm | |
Size of Strands | 0.25 mm | |
Maximum Operating Temperature | +70°C | |
Select all | ||
---|---|---|
Brand RS PRO | ||
Cross Sectional Area 1.5 mm² | ||
Number of Cores 5 | ||
Sheath Colour White | ||
Length 100m | ||
Current Rating 15 A | ||
Outer Diameter 3mm | ||
Sheath Material Polyvinyl Chloride PVC | ||
Voltage Rating 300/500 V | ||
Conductor Strand Type Stranded | ||
American Wire Gauge 15 AWG | ||
Conductor Resistance 13.3 Ω/km | ||
Minimum Operating Temperature -15°C | ||
Insulation Material PVC Type TI1 to BS7655 | ||
Standards Met BS EN 50525 | ||
Number of Strands 30 | ||
Conductor Material Copper | ||
Core Strands 30/0.25 mm | ||
Size of Strands 0.25 mm | ||
Maximum Operating Temperature +70°C | ||
- COO (Country of Origin):
- GB
BASEC approved H05VVF/3185Y 5 Core Cable
A light duty mains power cable that is ideal use in domestic appliances, kitchens and offices. They are also designed for use with light portable appliances such as radios, table lamps and office equipment.
Features and Benefits
PVC insulation and sheath
Flexible copper conductor - EN 60228 Class 5
Available in a range of sizes
BASEC certified
Note
Cable is not suitable for outdoor use or industrial applications
