Acc Silicones 740010410 Black Electrical Resistance Silicone Potting Compound

Technical Reference
Legislation and Compliance
RoHS Certificate of Compliance
COO (Country of Origin): GB
Product Details

Acc Silicones Potting Compound

The Acc silicones AS1701 75ml black silicon adhesive is a non-corrosive, one-part, room-temperature vulcanising silicon rubber, which exhibits excellent primer less adhesive properties with many substrates. It cures rapidly in contact with atmospheric moisture to a tough, moderately elastic rubber that exhibits excellent fire resistance.

Features and Benefits


Non-corrosive
• Excellent adhesion to many substrates
• Excellent electrical resistance
• Low linear shrinkage
• Fast skinning
• Cure through 2mm in 24 hours
• Flame retardant
• Cure time is 24 hours
• Hardness is 52 Shore A
• Thermal conductivity is 0.6W/mK
• Operating temperature ranges between -50⁰C and 220⁰C

Applications


Electronic assemblies
• Electrical assemblies

Silicone Compounds - ACC

Specifications
Attribute Value
Product Material Silicone
Package Type Cartridge
Package Size 75 ml
Special Properties Electrical Resistance
Cure Time 24 h
Hardness 52 Shore A
Thermal Conductivity 0.6W/mK
Colour Black
Maximum Operating Temperature +220°C
Minimum Operating Temperature -50°C
Operating Temperature Range -50 → +220 °C
125 In stock for FREE next working day delivery
Price Each
£ 28.88
(exc. VAT)
£ 34.66
(inc. VAT)
Units
Per unit
1 - 5
£28.88
6 - 14
£27.74
15 +
£27.15
