Vishay PE30 220Ω Rotary Potentiometer 1-Gang Panel Mount, PE30L0FR221KAB
- RS Stock No.:
- 790-4280
- Distrelec Article No.:
- 304-23-740
- Mfr. Part No.:
- PE30L0FR221KAB
- Brand:
- Vishay
Bulk discount available
Subtotal (1 unit)*
£38.34
(exc. VAT)
£46.01
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
- Plus 10 unit(s) ready to ship from another location
- Plus 52 unit(s) shipping from 09 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 1 | £38.34 |
2 - 4 | £35.65 |
5 - 9 | £32.59 |
10 - 24 | £30.67 |
25 + | £28.75 |
*price indicative
- RS Stock No.:
- 790-4280
- Distrelec Article No.:
- 304-23-740
- Mfr. Part No.:
- PE30L0FR221KAB
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Potentiometer Type | Rotary | |
Maximum Resistance | 220Ω | |
Number of Gangs | 1 | |
Number of Turns | 1 | |
Power Rating | 3W | |
Electrical Taper | Linear | |
Element Material | Cermet | |
Mounting Type | Panel Mount | |
Termination Style | Solder Lug | |
Shaft Length | 50mm | |
Shaft Diameter | 6 mm | |
Series | PE30 | |
Tolerance | ±10% | |
Actuator Type | Round Shaft | |
Select all | ||
---|---|---|
Brand Vishay | ||
Potentiometer Type Rotary | ||
Maximum Resistance 220Ω | ||
Number of Gangs 1 | ||
Number of Turns 1 | ||
Power Rating 3W | ||
Electrical Taper Linear | ||
Element Material Cermet | ||
Mounting Type Panel Mount | ||
Termination Style Solder Lug | ||
Shaft Length 50mm | ||
Shaft Diameter 6 mm | ||
Series PE30 | ||
Tolerance ±10% | ||
Actuator Type Round Shaft | ||
Vishay IP67 rated Military / Professional Grade Potentiometer - PE30 Series
Vishay brings you a range of brilliant potentiometers. These potentiometers are of the highest build quality and make great use in military and professional situations. They feature a fully sealed body and an IP67 rating making them great use in every scenario. These potentiometers feature a cermet element with through-hole mounting.
Features and Benefits:
• 19.7mm body
• High power ratings at 70°C
• Excellent thermal stability
• Robust construction with a fully sealed body. IP67 Rated
• Terminations for 0.11in. Receptacles 0.5mm thick
• Contact resistance variation 3% or 3Ω, whatever is greater.
• Insulation resistance of 105mΩ at 500Vdc
• Environmental class 55/125/56
• High power ratings at 70°C
• Excellent thermal stability
• Robust construction with a fully sealed body. IP67 Rated
• Terminations for 0.11in. Receptacles 0.5mm thick
• Contact resistance variation 3% or 3Ω, whatever is greater.
• Insulation resistance of 105mΩ at 500Vdc
• Environmental class 55/125/56
Note
Shaft dimension measurement includes bush
Supplied with
mounting nut and lock washer
