EMERSON – ASCO Pneumatic Solenoid Valve - 5/2 Solenoid G 521 Series 24V ac
- RS Stock No.:
- 122-759
- Mfr. Part No.:
- 52100002
- Brand:
- EMERSON ? ASCO
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£133.38
(exc. VAT)
£160.06
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2 unit(s) shipping from 10 August 2026
- Plus 3 unit(s) shipping from 14 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £133.38 |
| 5 + | £129.24 |
*price indicative
- RS Stock No.:
- 122-759
- Mfr. Part No.:
- 52100002
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EMERSON ? ASCO | |
| Product Type | Pneumatic Solenoid Valve | |
| Port Type | Push-in | |
| Port Size | 1/4 in | |
| Connection Thread Standard | G | |
| Actuation Type | Solenoid | |
| Series | 521 | |
| Voltage | 24V ac | |
| Seal Material | Nitrile Rubber (NBR) | |
| Mount Type | Manifold | |
| Number of Ports | 5 | |
| Body Material | Anodised Aluminium | |
| Maximum Operating Pressure | 8 bar | |
| Maximum Pilot Pressure | 8bar | |
| Valve Function | 5/2 | |
| Minimum Operating Temperature | 5°C | |
| Minimum Pilot Pressure | 1.5bar | |
| Maximum Flow Rate | 1050L/min | |
| Mount Pattern | DIN | |
| Maximum Operating Temperature | 50°C | |
| Solenoid Power Consumption | 2VA | |
| Height | 56.5mm | |
| Width | 22mm | |
| Standards/Approvals | RoHS | |
| Length | 131.3mm | |
| Hazardous Area Certification | No | |
| Electrical Connection Type | Plug Connector | |
| Select all | ||
|---|---|---|
Brand EMERSON ? ASCO | ||
Product Type Pneumatic Solenoid Valve | ||
Port Type Push-in | ||
Port Size 1/4 in | ||
Connection Thread Standard G | ||
Actuation Type Solenoid | ||
Series 521 | ||
Voltage 24V ac | ||
Seal Material Nitrile Rubber (NBR) | ||
Mount Type Manifold | ||
Number of Ports 5 | ||
Body Material Anodised Aluminium | ||
Maximum Operating Pressure 8 bar | ||
Maximum Pilot Pressure 8bar | ||
Valve Function 5/2 | ||
Minimum Operating Temperature 5°C | ||
Minimum Pilot Pressure 1.5bar | ||
Maximum Flow Rate 1050L/min | ||
Mount Pattern DIN | ||
Maximum Operating Temperature 50°C | ||
Solenoid Power Consumption 2VA | ||
Height 56.5mm | ||
Width 22mm | ||
Standards/Approvals RoHS | ||
Length 131.3mm | ||
Hazardous Area Certification No | ||
Electrical Connection Type Plug Connector | ||
RoHS Status: Exempt
- COO (Country of Origin):
- FR
519-520-521 series mini valves, assembly only or on manifold
3/2, 5/2 or 5/3 mini distributors for fitting onto manifolds or alone.
Stock numbers 302-6291 and 302-6308 fit onto manifolds only.
Monostable, bistable, closed centre or open centre versions.
Available in 3 different sizes: M5, G1/8" or G1/4".
