- RS Stock No.:
- 203-0529
- Mfr. Part No.:
- LR-3/4-D-O-MAXI
- Brand:
- Festo
Available to back order for despatch 05/08/2024, delivery within 2 working days
Price Each
£186.93
(exc. VAT)
£224.32
(inc. VAT)
Units | Per unit |
---|---|
1 + | £186.93 |
Not available for guaranteed pre 9am/10am delivery
Alternative
This product is not currently available. Here is our alternative recommendation.
- RS Stock No.:
- 203-0529
- Mfr. Part No.:
- LR-3/4-D-O-MAXI
- Brand:
- Festo
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- HU
Product Details
The Festo D series pressure regulator has a G 3/4 pneumatic port connecting thread with threaded connection plates. It is a directly-controlled diaphragm regulator design structure without pressure gauge. The regulator has a working pressure up to 12 bar.
Size = maxi
Actuator lock = rotary knob with lock
Assembly position = any
Actuator lock = rotary knob with lock
Assembly position = any
Specifications
Attribute | Value |
---|---|
Port Connection | G 3/4 |
Maximum Outlet Pressure | 12bar |
Minimum Outlet Pressure | 0.5bar |
Maximum Input Pressure | 16bar |
Manufacturer Series | D |
Typical Flow Rate | 11000L/min |
Model Number p | 162596 |
