EMERSON – ASCO G 1 Pneumatic Regulator - 16 bar, G653AR006GA00N0 10000 L/min G653
- RS Stock No.:
- 328-593
- Mfr. Part No.:
- G653AR006GA00N0
- Brand:
- EMERSON ? ASCO
Subtotal (1 unit)*
£151.31
(exc. VAT)
£181.57
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £151.31 |
*price indicative
- RS Stock No.:
- 328-593
- Mfr. Part No.:
- G653AR006GA00N0
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EMERSON ? ASCO | |
| Port Size | G 1 | |
| Product Type | Pneumatic Regulator | |
| Series | G653 | |
| Maximum Flow Rate | 10000L/min | |
| Maximum Operating Pressure | 16 bar | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | CUTR, ISO 8573.1:2010, ATEX, RoHS Status: Exempt | |
| Pressure Setting Range | 0.2 to 10 bar | |
| Select all | ||
|---|---|---|
Brand EMERSON ? ASCO | ||
Port Size G 1 | ||
Product Type Pneumatic Regulator | ||
Series G653 | ||
Maximum Flow Rate 10000L/min | ||
Maximum Operating Pressure 16 bar | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals CUTR, ISO 8573.1:2010, ATEX, RoHS Status: Exempt | ||
Pressure Setting Range 0.2 to 10 bar | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
The Asco Regulator ensures precise pressure control with high flow capacity and a wide range of adjustable output pressures to suit various pneumatic applications. It is available in relieving, non-relieving, and internal flow check options for enhanced versatility. Additionally, it offers multiple monitoring choices, including an optional low-profile gauge, round gauge, digital gauge, or digital pressure switch, providing flexibility for different system requirements.
Threaded ports allow for individual or modular mounting
Key lockable and tamper resistant options
