EMERSON – AVENTICS Rotary Knob 3/2 Pneumatic Manual Control Valve NL4-BAV Series, G 1/2, 1/2in, III B

RS Stock No.:: 703-6034
Mfr. Part No.:: 0821300911
Brand:: EMERSON – AVENTICS

EMERSON – AVENTICS Rotary Knob 3/2 Pneumatic Manual Control Valve NL4-BAV Series, G 1/2, 1/2in, III B

1 In stock - FREE next working day delivery available

7 available from Europe for delivery within 1 working day(s).

Added

Price Each

£72.61

(exc. VAT)

£87.13

(inc. VAT)

Units	Per unit
1 - 4	£72.61
5 +	£70.36

RS Stock No.:: 703-6034
Mfr. Part No.:: 0821300911
Brand:: EMERSON – AVENTICS

Technical Reference

3/2-shut-off valve, mechanically operated, Series NL4-BAV Data Sheet

Legislation and Compliance

RoHS Status: Not Applicable

COO (Country of Origin):: DE

Product Details

NL Series 3/2 Shut-Off Valve Manual

Shuts off supply pressure and gently relieves downstream pressure
Ball valve with metal to metal sealing
Padlock lockable
Working pressure 0 → 60 bar
Temperature range -10 → +60 °C
ATEX certified II 2G2D X

NL Series FRL

The NL range of air preparation units may be used as single elements or in combination units using joining accessories

Specifications

Attribute	Value
Control Mechanism	Rotary Knob
Connection Port Thread	G 1/2
Function	3/2
Thread Size	1/2in
Thread Standard	G
Manufacturer Series	NL4-BAV
Maximum Operating Pressure	16 bar
Body Material	Die Cast Zinc
Maximum Flow Rate	11000L/min
Minimum Operating Temperature	-10°C
Maximum Operating Temperature	+60°C
Number of Ports	3/2
