Festo 3/2 Closed, Monostable Pneumatic Manual Control Valve HEE-1/4-D-MINI-230 Series, G 1/4, G 1/8, 1/4in, 165073
- RS Stock No.:
- 203-8667
- Mfr. Part No.:
- HEE-1/4-D-MINI-230
- Brand:
- Festo
Subtotal (1 unit)*
£141.41
(exc. VAT)
£169.69
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £141.41 |
*price indicative
- RS Stock No.:
- 203-8667
- Mfr. Part No.:
- HEE-1/4-D-MINI-230
- Brand:
- Festo
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Festo | |
Connection Port Thread | G 1/4, G 1/8 | |
Function | 3/2 Closed, Monostable | |
Thread Size | 1/4in | |
Thread Standard | G | |
Manufacturer Series | HEE-1/4-D-MINI-230 | |
Maximum Operating Pressure | 16 bar | |
Body Material | Aluminium | |
Minimum Operating Temperature | -10°C | |
Maximum Operating Temperature | +60°C | |
Number of Ports | 3 | |
Number of Positions | 2 | |
Model Number p | 165073 | |
Select all | ||
---|---|---|
Brand Festo | ||
Connection Port Thread G 1/4, G 1/8 | ||
Function 3/2 Closed, Monostable | ||
Thread Size 1/4in | ||
Thread Standard G | ||
Manufacturer Series HEE-1/4-D-MINI-230 | ||
Maximum Operating Pressure 16 bar | ||
Body Material Aluminium | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature +60°C | ||
Number of Ports 3 | ||
Number of Positions 2 | ||
Model Number p 165073 | ||
- COO (Country of Origin):
- HU
Festo Pneumatic Manual Control Valve, G1/4 Thread, 3/2 Function - HEE-1/4-D-MINI-230
Manage the movement of air in your pneumatic system using this manual control valve from Festo. As it's a 3/2 valve, it can move in two directions to direct the air through three different ports. You can use this component with both compressed air and inert gases making it a versatile choice. A nominal flow rate of 1,500l/min means it can withstand high-flow applications. For durability, the device's aluminium die-cast housing is resistant to impacts and corrosion. You can mount this valve in any position for flexibility in your setup.
• Light weight of 223g for minimal strain on equipment
• Broad operating temperature range between -10°C and +60°C to withstand harsh environments
• NBR seals are resistant to oils and chemicals for added robustness
• Mechanical spring reset for rapid operation
• Broad operating temperature range between -10°C and +60°C to withstand harsh environments
• NBR seals are resistant to oils and chemicals for added robustness
• Mechanical spring reset for rapid operation
Applications
• Marine engineering
• Packaging industry
• Industrial cylinders
• Packaging industry
• Industrial cylinders
How much pressure can this valve withstand?
This valve has an operating pressure range between 2.5 and 16 bar, which means it can withstand both low-pressure and high-pressure systems.
What type of power source does this valve use?
This valve is powered electronically. You can connect it to a power source through its built-in plug or via a DIN rail.
