SMC AS Series Speed Controller Speed Controller, AS1301FS-M5-06A, Inlet Male, M5 Metric M5 x 0.8, Outlet Female Tube
- RS Stock No.:
- 393-645
- Mfr. Part No.:
- AS1301FS-M5-06A
- Brand:
- SMC
Subtotal (1 unit)*
£12.13
(exc. VAT)
£14.56
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 21 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £12.13 |
*price indicative
- RS Stock No.:
- 393-645
- Mfr. Part No.:
- AS1301FS-M5-06A
- Brand:
- SMC
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SMC | |
| Product Type | Speed Controller | |
| Inlet Connection Type | M5 | |
| Outlet Connection Type | Tube One-Touch Fitting | |
| Sub Type | Speed Controller | |
| Inlet Connection Size | M5 x 0.8 | |
| Outlet Connection Size | 6 mm | |
| Series | AS | |
| Inlet Thread Standard | Metric | |
| Inlet Port Gender | Male | |
| Maximum Operating Pressure | 1 Mpa | |
| Minimum Operating Temperature | -5°C | |
| Outlet Port Gender | Female | |
| Material | Polybutylene Terephthalate, Brass | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | ISO 10218-1, RoHS, IEC 60204-1, ISO 4413, ISO 4414 | |
| Hazardous Area Certification | No | |
| Minimum Operating Pressure | 0.1MPa | |
| Proof Pressure | 1.5MPa | |
| Model Number | AS1301FS-M5-06A | |
| Select all | ||
|---|---|---|
Brand SMC | ||
Product Type Speed Controller | ||
Inlet Connection Type M5 | ||
Outlet Connection Type Tube One-Touch Fitting | ||
Sub Type Speed Controller | ||
Inlet Connection Size M5 x 0.8 | ||
Outlet Connection Size 6 mm | ||
Series AS | ||
Inlet Thread Standard Metric | ||
Inlet Port Gender Male | ||
Maximum Operating Pressure 1 Mpa | ||
Minimum Operating Temperature -5°C | ||
Outlet Port Gender Female | ||
Material Polybutylene Terephthalate, Brass | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals ISO 10218-1, RoHS, IEC 60204-1, ISO 4413, ISO 4414 | ||
Hazardous Area Certification No | ||
Minimum Operating Pressure 0.1MPa | ||
Proof Pressure 1.5MPa | ||
Model Number AS1301FS-M5-06A | ||
- COO (Country of Origin):
- JP
SMC Series AS Speed Controller, 6mm Outlet size, 1MPa Maximum Operating Pressure - AS1301FS-M5-06A
This speed controller provides adjustable Airflow regulation for pneumatic systems, designed for integration into industrial automation and machinery. It connects directly via a metric M5 male inlet and delivers Air through a 6mm push-in tube outlet, enabling controlled actuator motion in manufacturing and process equipment. Constructed from polymer and metal elements, it operates across typical workshop temperature ranges and is suitable where compact, inline flow control is required.
Features & Benefits
• Maximum operating pressure 1MPa for higher system loads
• Minimum operating pressure 0.1MPa supports low-pressure control
• Proof pressure 1.5MPa increases system safety margin
• Operating temperature range -5°C to 60°C for varied environments
• PBT and brass construction resists wear in industrial use
• Minimum operating pressure 0.1MPa supports low-pressure control
• Proof pressure 1.5MPa increases system safety margin
• Operating temperature range -5°C to 60°C for varied environments
• PBT and brass construction resists wear in industrial use
**Applications**
• Suitable for regulating cylinder speed in automated actuators
• Ideal for pneumatic tooling on assembly lines
• Used with small bore tubing in control panels
• Can be used for flow control in pick-and-place devices
• Ideal for pneumatic tooling on assembly lines
• Used with small bore tubing in control panels
• Can be used for flow control in pick-and-place devices
What inlet and outlet connections does it use?
It accepts a metric M5 male-threaded inlet and provides a 6mm one-touch tube outlet for quick pneumatic tubing connection.
What standards does it conform to for industrial use?
It meets ISO 4413 and ISO 4414 requirements and adheres to IEC 60204-1 and ISO 10218-1 where relevant, and it is RoHS compliant.
What materials comprise the device and why does that matter?
The body combines polybutylene terephthalate with brass components, offering a balance of lightweight corrosion resistance and Durable threaded interfaces.
How does the device perform under thermal stress?
It functions reliably within a -5°C to 60°C range, suitable for typical indoor industrial environments and moderate ambient variations.
