Legris 3321 Series, Male/Female, M40 x 1.5, M46 x 1.5, Metric
- RS Stock No.:
- 366-9775
- Mfr. Part No.:
- 3321 06 00 04
- Brand:
- Legris
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 366-9775
- Mfr. Part No.:
- 3321 06 00 04
- Brand:
- Legris
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Legris | |
| Product Type | Pneumatic Fitting | |
| Connection Thread Size | M40 x 1.5, M46 x 1.5 | |
| Connection Thread Standard | Metric | |
| Series | 3321 | |
| Connection Gender | Male/Female | |
| Material | Stainless Steel, Technical Polymer | |
| Tube Connection Type | Push-in | |
| Tube Connection Size | 6mm | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Legris | ||
Product Type Pneumatic Fitting | ||
Connection Thread Size M40 x 1.5, M46 x 1.5 | ||
Connection Thread Standard Metric | ||
Series 3321 | ||
Connection Gender Male/Female | ||
Material Stainless Steel, Technical Polymer | ||
Tube Connection Type Push-in | ||
Tube Connection Size 6mm | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- GB
Tube/Coil Multitube Female Body
Multitube-Coil & Connector - Legris
Compact and flexible cabling - specially designed assembly ensures small bend radii
PVC sheath with proven resistance to abrasion, fire, caustic fluids, oils, alcohols, etc
Numbered and colour coded tubes for fast circuit identification
Full bore design, ideal for bulkhead use
