SMC KQ2 Series Straight Tube-to-Tube Adaptor, Push In 8 mm to Push In 10 mm, Tube-to-Tube Connection Style

View all Pneumatic Fittings
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
Photo of Pneumatic Fittings & Air Hose
Explore our Air hose range
Need compressed air system for your fittings? You’re in the right place. Our wide range of air hoses includes everything you need—all designed for secure, efficient performance. With both fittings and hoses available side by side, it’s easy to find compatible components and build a complete setup that works for your space and application.
Shop Now
RS Stock No.:
163-2994
Mfr. Part No.:
KQ2H08-10A(10)
Brand:
SMC
Find similar products by selecting one or more attributes.
Select all

Brand

SMC

Connector A

Push In 8 mm

Connector B

Push In 10 mm

Pneumatic Fitting Type

Straight Tube-to-Tube Adaptor

Connection Style

Tube-to-Tube

Manufacturer Series

KQ2

Body Material

PBT, Polypropylene

Maximum Operating Pressure

1 MPa

Maximum Operating Temperature

+40 °C, +60°C

Minimum Operating Temperature

-5 °C, 0°C

COO (Country of Origin):
JP
KQ2 one-touch, metric and inch size fittings are available in a wide variety of sizes, body styles and thread types. The specially designed packing provides positive sealing under pressure without the reduced flow common with compression fittings. The KQ2 release collar releases both the chuck and collet to provide a low disconnection force for easy removal of the tubing

Accepts nylon and urethane tubes
Applicable for both vacuum and positive pressure applications
Release collar allows easy removal of tubing without damaging the tube
Maximum vacuum pressure of 1.0MPa
