RS PRO Elbow Tube-toTube Adaptor, Push In 12 mm to Push In 6 mm, Push-in Connection Style
- RS Stock No.:
- 528-571
- Brand:
- RS PRO
Subtotal (1 bag of 5 units)*
£13.06
(exc. VAT)
£15.67
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 7 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £13.06 | £2.612 |
*price indicative
- RS Stock No.:
- 528-571
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Connector A | Push In 12 mm | |
| Connector B | Push In 6 mm | |
| Pneumatic Fitting Type | Elbow Tube-toTube Adaptor | |
| Connection Style | Push-in | |
| Number of Inlet Ports | 1 | |
| Number of Outlet Ports | 1 | |
| Maximum Operating Pressure | 10bar | |
| Minimum Operating Temperature | 1°C | |
| Angle | 90° | |
| Mounting Type | Inline | |
| Body Material | Acetal Copolymer | |
| Food Grade | Yes | |
| Maximum Operating Temperature | 65°C | |
| Standards Met | ACS, DM174/2004, EC1935/2004 , ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270 and KTW, WRAS | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Connector A Push In 12 mm | ||
Connector B Push In 6 mm | ||
Pneumatic Fitting Type Elbow Tube-toTube Adaptor | ||
Connection Style Push-in | ||
Number of Inlet Ports 1 | ||
Number of Outlet Ports 1 | ||
Maximum Operating Pressure 10bar | ||
Minimum Operating Temperature 1°C | ||
Angle 90° | ||
Mounting Type Inline | ||
Body Material Acetal Copolymer | ||
Food Grade Yes | ||
Maximum Operating Temperature 65°C | ||
Standards Met ACS, DM174/2004, EC1935/2004 , ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270 and KTW, WRAS | ||
- COO (Country of Origin):
- KR
RS PRO Pneumatic Fitting, Reducing Elbow, 12 mm to 6 mm
This RS PRO pneumatic fitting is a reducing elbow designed for efficient fluid transfer in various industrial applications. It connects a 12 mm tube to a 6 mm tube, making it ideal for systems requiring a change in tube diameter. The fitting is constructed from acetal copolymer, ensuring durability and compliance with multiple international standards.
Features and Benefits
Fluidfit design: Suitable for water, food, and air contact, with additional compatibility for selected gases, vacuum, and liquids, enhancing versatility.
Quick connection and release: Easy actions allow the tube to be connected and released quickly, saving time and expenses.
Non-toxic materials: Made from NSF and ACS approved materials, ensuring safety in food and beverage applications.
High pressure tolerance: Operates efficiently up to 10 bar, suitable for demanding environments.
Wide temperature range: Functions effectively between 1 °C and 65 °C, accommodating various operational conditions.
Inline mounting: Simplifies installation and integration into existing systems.
Quick connection and release: Easy actions allow the tube to be connected and released quickly, saving time and expenses.
Non-toxic materials: Made from NSF and ACS approved materials, ensuring safety in food and beverage applications.
High pressure tolerance: Operates efficiently up to 10 bar, suitable for demanding environments.
Wide temperature range: Functions effectively between 1 °C and 65 °C, accommodating various operational conditions.
Inline mounting: Simplifies installation and integration into existing systems.
Applications
Water
Beverage
Vacuum
Compressed air
Gases and liquids suitable with construction material
Beverage
Vacuum
Compressed air
Gases and liquids suitable with construction material
Additional Information
Complies with ACS, DM174/2004, EC1935/2004, ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270, KTW, and WRAS standards, ensuring broad regulatory acceptance across multiple markets.
