RS PRO Straight Tube-to-Tube Adaptor, Push In 8 mm to Push In 4 mm, Push-in Connection Style
- RS Stock No.:
- 528-433
- Brand:
- RS PRO
Subtotal (1 bag of 5 units)*
£11.23
(exc. VAT)
£13.48
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 8 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £11.23 | £2.246 |
*price indicative
- RS Stock No.:
- 528-433
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Connector A | Push In 8 mm | |
| Connector B | Push In 4 mm | |
| Pneumatic Fitting Type | Straight Tube-to-Tube Adaptor | |
| Connection Style | Push-in | |
| Number of Inlet Ports | 1 | |
| Number of Outlet Ports | 1 | |
| Minimum Operating Temperature | 1°C | |
| Body Material | Acetal Copolymer | |
| Food Grade | Yes | |
| Maximum Operating Pressure | 10bar | |
| Angle | Straight | |
| Maximum Operating Temperature | 65°C | |
| Mounting Type | Inline | |
| Standards Met | ACS, DM174/2004, EC1935/2004 , ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270 and KTW, WRAS | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Connector A Push In 8 mm | ||
Connector B Push In 4 mm | ||
Pneumatic Fitting Type Straight Tube-to-Tube Adaptor | ||
Connection Style Push-in | ||
Number of Inlet Ports 1 | ||
Number of Outlet Ports 1 | ||
Minimum Operating Temperature 1°C | ||
Body Material Acetal Copolymer | ||
Food Grade Yes | ||
Maximum Operating Pressure 10bar | ||
Angle Straight | ||
Maximum Operating Temperature 65°C | ||
Mounting Type Inline | ||
Standards Met ACS, DM174/2004, EC1935/2004 , ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270 and KTW, WRAS | ||
- COO (Country of Origin):
- KR
RS PRO Reducing Union Straight Pneumatic Fitting, 8 mm to 4 mm
This RS PRO reducing union straight pneumatic fitting is designed to connect tubes of different diameters, specifically from 8 mm to 4 mm. It is ideal for applications requiring reliable and quick connections in pneumatic systems, offering a seamless transition between tube sizes. The fitting is constructed from acetal copolymer, ensuring durability and compliance with various international standards for food and water contact.
Features and Benefits
Fluidfit design: Suitable for water, food, and air contact, and compatible with selected gases, vacuum, and liquids, providing versatility in application.
Quick connection and release: Easy actions allow the tube to be connected and released quickly, saving time and expenses.
Non-toxic material: Made from NSF and ACS approved materials, ensuring safety and compliance with food-grade standards.
High pressure tolerance: Operates effectively up to a maximum pressure of 10 bar, suitable for demanding environments.
Temperature range: Functions efficiently between 1 °C and 65 °C, accommodating various operational conditions.
Push-in connection style: Simplifies installation and maintenance, enhancing user convenience.
Quick connection and release: Easy actions allow the tube to be connected and released quickly, saving time and expenses.
Non-toxic material: Made from NSF and ACS approved materials, ensuring safety and compliance with food-grade standards.
High pressure tolerance: Operates effectively up to a maximum pressure of 10 bar, suitable for demanding environments.
Temperature range: Functions efficiently between 1 °C and 65 °C, accommodating various operational conditions.
Push-in connection style: Simplifies installation and maintenance, enhancing user convenience.
Applications
Water
Beverage
Vacuum
Compressed air
Gases and liquids suitable with construction material
Beverage
Vacuum
Compressed air
Gases and liquids suitable with construction material
Additional Information
Complies with international standards such as ACS, DM174/2004, EC1935/2004, ISO9001, ISO14001, NSF 51, NSF 61, Reach and RoHS 3, W270, KTW, and WRAS, ensuring global applicability and safety.
