Phoenix Contact 3.81mm Pitch 17 Way Pluggable Terminal Block, Header, Solder Termination
- RS Stock No.:
- 881-9492
- Mfr. Part No.:
- 1844935
- Brand:
- Phoenix Contact
Available to back order for despatch 21/06/2024
Added
Price Each (In a Box of 50)
£3.784
(exc. VAT)
£4.541
(inc. VAT)
| Units | Per unit | Per Box* |
| 50 + | £3.784 | £189.20 |
| *price indicative | ||
- RS Stock No.:
- 881-9492
- Mfr. Part No.:
- 1844935
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB headers, nominal cross section: 1.5 mm², color: green, nominal current: 8 A, rated voltage (III/2): 160 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 17, Number of rows: 1, Number of positions per row: 17, number of connections: 17, product range: MCV 1,5/..-GF, pitch: 3.81 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.4 mm, Stecksystem: MINI COMBICON, Locking: Screw locking, type of packaging: packed in cardboard
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Header |
| Number of Contacts | 17 |
| Pitch | 3.81mm |
| Series | MCV 1.5/17-GF-3.81 |
| Termination Method | Solder |
| Current Rating | 8.0A |
| Voltage Rating | 250.0 V |
| Contact Material | Tin |
