Phoenix Contact 7.62mm Pitch 8 Way Pluggable Terminal Block, Plug, Cable Mount, Screw Termination
- RS Stock No.:
- 855-1559
- Mfr. Part No.:
- 1714333
- Brand:
- Phoenix Contact
Available to back order for despatch 09/08/2024
Price Each (In a Box of 50)
£12.336
(exc. VAT)
£14.803
(inc. VAT)
Units | Per unit | Per Box* |
|---|---|---|
| 50 + | £12.336 | £616.80 |
*price indicative
- RS Stock No.:
- 855-1559
- Mfr. Part No.:
- 1714333
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB connector, nominal cross section: 2.5 mm², color: green, nominal current: 16 A, rated voltage (III/2): 1000 V, contact surface: Tin, type of contact: Female connector, Number of potentials: 8, Number of rows: 1, Number of positions per row: 8, number of connections: 8, product range: GMSTB 2,5 HCV/..-ST, pitch: 7.62 mm, connection method: Screw connection with tension sleeve, conductor/PCB connection direction: 0 °, Stecksystem: POWER COMBICON 2,5, Locking: without, type of packaging: packed in cardboard
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Plug |
| Number of Contacts | 8 |
| Pitch | 7.62mm |
| Series | GMSTB 2.5 HCV/ 8-ST-7.62 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Mounting Type | Cable Mount |
| Termination Method | Screw |
| Current Rating | 16A |
| Voltage Rating | 1 kV |
| Colour | Green |
| Material | Polyamide, Tin |
