- RS Stock No.:
- 854-1039
- Mfr. Part No.:
- 1971206
- Brand:
- Phoenix Contact
Available to back order for despatch 05/08/2024
Price Each (In a Box of 50)
£15.799
(exc. VAT)
£18.959
(inc. VAT)
Units | Per unit | Per Box* |
50 + | £15.799 | £789.95 |
*price indicative |
- RS Stock No.:
- 854-1039
- Mfr. Part No.:
- 1971206
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB connector, nominal cross section: 2.5 mm², color: green, nominal current: 12 A, rated voltage (III/2): 320 V, contact surface: Tin, type of contact: Female connector, Number of potentials: 16, Number of rows: 1, Number of positions per row: 16, number of connections: 16, product range: SMSTB 2,5/..-STF, pitch: 5.08 mm, connection method: Screw connection with tension sleeve, conductor/PCB connection direction: -45 °, Stecksystem: CLASSIC COMBICON, Locking: Screw locking, type of packaging: packed in cardboard
Specifications
Attribute | Value |
---|---|
Pluggable Terminal Block Type | Plug |
Number of Contacts | 16 |
Pitch | 5.08mm |
Series | SMSTB 2.5/16-STF-5.08 |
Termination Method | Screw |
Current Rating | 12A |
Voltage Rating | 630 V |
Colour | Green |
Material | Polyamide, Tin |
