Phoenix Contact 7.62mm Pitch 7 Way Pluggable Terminal Block, Header, Through Hole, Solder Termination
- RS Stock No.:
- 853-9118
- Mfr. Part No.:
- 1792407
- Brand:
- Phoenix Contact
Available to back order for despatch 18/06/2024
Added
Price Each (In a Box of 50)
£1.518
(exc. VAT)
£1.822
(inc. VAT)
| Units | Per unit | Per Box* |
| 50 + | £1.518 | £75.90 |
| *price indicative | ||
- RS Stock No.:
- 853-9118
- Mfr. Part No.:
- 1792407
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
PCB headers, nominal cross section: 2.5 mm², color: green, nominal current: 16 A, rated voltage (III/2): 630 V, contact surface: Tin, type of contact: Male connector, Number of potentials: 7, Number of rows: 1, Number of positions per row: 7, number of connections: 7, product range: GMSTBVA 2,5 HC/..-G, pitch: 7.62 mm, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.9 mm, Stecksystem: POWER COMBICON 2,5, Locking: without, type of packaging: packed in cardboard
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Header |
| Number of Contacts | 7 |
| Pitch | 7.62mm |
| Series | GMSTBVA 2.5 HC/ 7-G-7.62 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Termination Method | Solder |
| Current Rating | 16.0A |
| Voltage Rating | 630.0 V |
| Contact Material | Tin |
