Weidmuller, 5.08mm Pitch, OMNIMATE SL, 11 Way, , Pluggable Terminal Block, Header, Through Hole, Solder Termination,

View all Pluggable Terminal Blocks
Bulk discount available

Subtotal (1 pack of 5 units)*

£10.84

(exc. VAT)

£13.01

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 95 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
5 - 120£2.168£10.84
125 - 370£1.672£8.36
375 - 995£1.43£7.15
1000 - 1995£1.392£6.96
2000 +£1.356£6.78

*price indicative

RS Stock No.:
733-0588
Distrelec Article No.:
304-24-238
Mfr. Part No.:
1147610000
Brand:
Weidmüller
Find similar products by selecting one or more attributes.
Select all

Brand

Weidmüller

Pluggable Terminal Block Type

Header

Number of Contacts

11

Pitch

5.08mm

Series

OMNIMATE SL

Number of Rows

1

Body Orientation

Straight

Mounting Type

Through Hole

Termination Method

Solder

Current Rating

18.0A

Voltage Rating

400.0 V

Colour

Orange

Contact Material

Copper Alloy

COO (Country of Origin):
DE

Weidmuller OMNIMATE SL Series Pluggable Terminal Block, 18A Current Rating, 400V Voltage Rating - 1147610000


The Weidmuller pluggable terminal block is a high-quality header terminal block designed for efficient electrical connections. With a compact 5.08mm pitch, it features 11 contacts, making it suitable for applications requiring secure connectivity. The through-hole mounting style ensures a stable fit, and the solder termination method promotes robust connections for various electronic applications.

Features & Benefits


• 11 contacts support multiple connections
• High current rating of 18A for performance
• Voltage rating of 400V for safe operation
• Straight body orientation simplifies installation
• Copper alloy contacts enhance conductivity and durability
• Bright orange colour offers visibility for easy identification

Applications


• Connecting wires in automation systems
• Suitable for electrical control panels
• Ideal for PCB (Printed Circuit Board) assemblies
• Utilised in machinery and equipment necessitating secure connections

Can it handle high current applications?


Yes, it supports a current rating of 18.0A.

Will it fit standard PCB layouts?


The straight orientation and 5.08mm pitch accommodate various layouts.

Is soldering required for installation?


Yes, it uses a solder termination method for secure connections.

What is the maximum operating temperature for this connector?


The connector can operate within a temperature range of -50°C to 100°C.


5.08mm Pitch -Weidmüller Omnimate Range


Weidmüller's Omnimate Range of 5.08mm pitch Two Part connectors allows wire-to-board connections through terminals using Leaf Spring and Spring Rising Clamp screw technology, or Tension Clamp and Push In screwless technology. The Weidmuller 8 Way Clamp Rising Terminal is suitable for a wide range of PCB design and connector uses.


• The PCB hole has a diameter of 1.3mm
• Screw clamp types accept wire up to 1.5mm²
• Tension clamp and IDC (screwless) options enable fast assembly times
• Moulded male headers in straight (open or closed end) 90° PCB pins or 135° headers
• Polarising pins prevent mismatch connections.
