WAGO 733 Series Pluggable Terminal Block, 3-Contact, 2.5 mm Pitch, 1 Row, 733-103-1
- RS Stock No.:
- 288-5258
- Mfr. Part No.:
- 733-103-1
- Brand:
- WAGO
Subtotal (1 box of 200 units)*
£418.72
(exc. VAT)
£502.46
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 1 unit(s) shipping from 23 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £418.72 | £2.094 |
*price indicative
- RS Stock No.:
- 288-5258
- Mfr. Part No.:
- 733-103-1
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 3 | |
| Product Type | Pluggable Terminal Block | |
| Pitch | 2.5mm | |
| Current | 4A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 0.5mm² | |
| Connector Gender | Female | |
| Minimum Wire Size AWG | 28 AWG | |
| Maximum Wire Size AWG | 28 AWG | |
| Orientation | Straight | |
| Colour | Light Grey | |
| Voltage | 320 V | |
| Standards/Approvals | RoHS | |
| Series | 733 | |
| Width | 7.1 mm | |
| Length | 5mm | |
| Depth | 17.1mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 3 | ||
Product Type Pluggable Terminal Block | ||
Pitch 2.5mm | ||
Current 4A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 0.5mm² | ||
Connector Gender Female | ||
Minimum Wire Size AWG 28 AWG | ||
Maximum Wire Size AWG 28 AWG | ||
Orientation Straight | ||
Colour Light Grey | ||
Voltage 320 V | ||
Standards/Approvals RoHS | ||
Series 733 | ||
Width 7.1 mm | ||
Length 5mm | ||
Depth 17.1mm | ||
- COO (Country of Origin):
- DE
The WAGO 1-conductor female connector having CAGE CLAMP connection technology. It has nominal cross section of 0.5 mm² and pin spacing of 2.5 mm.
Universal connection for all conductor types
Easy cable pre-assembly and on-unit wiring via vertical and horizontal CAGE CLAMP actuation
For wire-to-wire and board-to-wire connections
Versions available with snap-in mounting feet or flanges for panel o
