Phoenix Contact MCVW 1,5 Series PCB Connector Accessory, 5-Contact, 3.5 mm Pitch, 1 Row, 1862881
- RS Stock No.:
- 265-7447
- Mfr. Part No.:
- 1862881
- Brand:
- Phoenix Contact
Subtotal (1 pack of 250 units)*
£784.25
(exc. VAT)
£941.00
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 02 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 250 + | £3.137 | £784.25 |
*price indicative
- RS Stock No.:
- 265-7447
- Mfr. Part No.:
- 1862881
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 5 | |
| Product Type | PCB Connector Accessory | |
| Pitch | 3.5mm | |
| Current | 8A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 2mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | -90° | |
| Wire Connection Method | Screw Connection with Tension Sleeve | |
| Colour | Green | |
| Voltage | 160V | |
| Length | 10.4mm | |
| Width | 18.3mm | |
| Standards/Approvals | IEC 60068-2-82/JEDEC JESD 201, DE1-60987-B1B2, B.01687, E60425-20110128, 40011723 | |
| Series | MCVW 1,5 | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 5 | ||
Product Type PCB Connector Accessory | ||
Pitch 3.5mm | ||
Current 8A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 2mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation -90° | ||
Wire Connection Method Screw Connection with Tension Sleeve | ||
Colour Green | ||
Voltage 160V | ||
Length 10.4mm | ||
Width 18.3mm | ||
Standards/Approvals IEC 60068-2-82/JEDEC JESD 201, DE1-60987-B1B2, B.01687, E60425-20110128, 40011723 | ||
Series MCVW 1,5 | ||
- COO (Country of Origin):
- DE
The Phoenix Contact PCB connector has rated voltage 160 V, 8 A nominal current and tin contact surface, screw connection with green color.
Without mounting flange
Copper alloy contact material
